Wehrli WCF100414-IP Stage 2 HF Intake Bundle Illusion Purple 2020-26 L5P Duramax

Vehicle Fitment

• 2020-2026 Chevrolet Silverado 2500HD (6.6L Duramax L5P, 4WD/2WD - All Trims)
• 2020-2026 Chevrolet Silverado 3500HD (6.6L Duramax L5P, 4WD/2WD - All Trims)
• 2020-2026 GMC Sierra 2500HD (6.6L Duramax L5P, 4WD/2WD - All Trims)
• 2020-2026 GMC Sierra 3500HD (6.6L Duramax L5P, 4WD/2WD - All Trims)

Fitment Notes

• Compatible with the OEM turbocharger and upgraded drop-in style VGT turbochargers. Best results when paired with emissions-compliant tuning.
• After installation, the vehicle's air filter monitor system must be disabled in the instrument cluster settings. Failure to do so will result in a "Service Air Filter" dashboard message that requires a dealership reset to clear.
• Draws cold air through the functional hood Ram Air duct and inner fender - requires the OEM Ram Air hood or compatible replacement.
• No tuning required for installation. Compatible with stock trucks - no additional modifications or upgrades necessary.
• This listing is for the Illusion Purple (-IP) powder coat color option.
• This product cannot ship to the State of California.

Features

• Combines the Stage 1 High Flow Intercooler Pipe Bundle (WCF100410) and Stage 2 Intake Kit (WCF100684) into a single comprehensive package - saving approximately $64 versus purchasing components separately.
• High-flow 4" 14-gauge aluminum intake pipe with smooth aerodynamic mandrel bends replaces the restrictive OEM plastic factory intake for improved air velocity, volume, and a more aggressive engine and turbo sound.
• 4" CNC machined cast aluminum intake horn with PCV port and surge ring - over 1" larger than OEM diameter - eliminates the factory restriction before the turbo inlet.
• 10-gauge aluminum air box and lid encloses the filter from engine heat and debris, with a removable lid for easy inspection and maintenance.
• Draws cold, dense air through the hood Ram Air duct and inner fender for cooler intake charge temperatures and improved turbo efficiency.
• Dry air filter and Outerwears hydrophobic pre-filter cover included to protect the MAF sensor, turbocharger, and engine airways from contaminants.
• 3" Driver (Hot) Side intercooler pipe eliminates the OEM 2-piece resonator-equipped 2.5" pipe and middle boot joint - reinforced silicone boots and stainless T-bolt clamps replace factory joints.
• 3.5" Passenger (Cold) Side intercooler pipe features a CNC machined flange with black anodized billet aluminum adapter and double O-rings - eliminates the OEM clip ring design with a high-quality silicone boot and T-bolt clamp for superior boost pressure retention.
• All intercooler pipe connections retain factory sensor locations and OEM connection points.
• Full assembly finished in Illusion Purple powder coat - Made in the USA by Wehrli Custom Fabrication.

Specifications

• Part Number: WCF100414-IP
• Color/Finish: Illusion Purple Powder Coat
• Intake Pipe Diameter: 4"
• Intake Pipe Material: 14-gauge mandrel bent aluminum
• Intake Horn Inlet: 4" CNC machined cast aluminum with PCV port and surge ring
• Air Box Material: 10-gauge aluminum sheet
• Hot Side Intercooler Pipe Diameter: 3"
• Cold Side Intercooler Pipe Diameter: 3.5"
• Intercooler Pipe Material: 14-gauge mandrel bent aluminum
• Cold Side Adapter: CNC machined black anodized billet aluminum with double O-rings
• Filter Type: Dry air filter
• Pre-Filter Cover: Outerwears hydrophobic cover included
• Hardware: Silicone boots, stainless steel T-bolt clamps, O-rings, intercooler outlet clip
• Country of Origin: USA

Included Components

• 1x 4" 14-gauge aluminum intake pipe (Illusion Purple powder coated)
• 1x 4" CNC machined cast aluminum intake horn with PCV port and surge ring (Illusion Purple powder coated)
• 1x 10-gauge aluminum air box with lid (Illusion Purple powder coated)
• 1x Dry air filter
• 1x Outerwears hydrophobic pre-filter cover
• 1x 4" silicone hump boot
• 1x 3" hot side intercooler pipe (Illusion Purple powder coated)
• 1x 3.5" cold side intercooler pipe (Illusion Purple powder coated)
• 1x CNC machined black anodized billet aluminum cold side adapter
• High-quality silicone boots and stainless steel T-bolt clamps (all connections)
• O-ring set and intercooler outlet clip
• Seal for functional Ram Air hood port connection
• Installation hardware kit

Product Description

The Wehrli WCF100414-IP is the Stage 2 High Flow Intake Bundle for 2020-2026 Chevrolet Silverado and GMC Sierra 2500HD/3500HD trucks with the 6.6L L5P Duramax. It combines the Stage 1 High Flow Intercooler Pipe Bundle and Stage 2 Intake Kit into one complete package, addressing both sides of the factory airflow restrictions - before and after the turbocharger. The result is improved horsepower, torque, throttle response, turbo spool-up, and cooler intake temperatures, all from a bolt-on kit that requires no tuning.

On the intake side, a 4" aluminum pipe and over-sized cast aluminum intake horn draw cold air from the hood Ram Air duct and inner fender, feeding the turbo more efficiently than the restrictive OEM plastic system. On the intercooler side, the OEM 2.5" multi-piece resonator-equipped hot side pipe and failure-prone plastic/rubber cold side pipe are replaced with WCFab's heavy-duty 3" and 3.5" one-piece aluminum pipes, eliminating boost leaks and weak OEM connection points. Finished in Illusion Purple powder coat and made in the USA, the WCF100414-IP saves approximately $64 compared to purchasing the Stage 1 and Stage 2 components individually.
