Turbosmart TS-0223-1284 Kompact EM Plumb Back BOV VR15 Fiat/Abarth/Alfa Romeo

Vehicle Fitment

• 2017-2020 Fiat 124 Spider Abarth 1.4L Turbo MultiAir
• 2017-2020 Fiat 124 Spider 1.4L Turbo MultiAir
• 2008-2010 Abarth Grande Punto 1.4L Turbo
• 2010-2015 Abarth Punto Evo 1.4L Turbo
• 2017-2025 Alfa Romeo Giulia 2.0L Turbo
• 2010-2020 Alfa Romeo Giulietta 1.4L Turbo MultiAir
• 2009-2018 Alfa Romeo Mito 0.9L TwinAir Turbo / 1.4L Turbo MultiAir
• 2012-2019 Fiat 500 Abarth 1.4L Turbo (North American / Mexico-Built Models)
• 2010-2019 Fiat 500 0.9L TwinAir Turbo
• 2007-2014 Fiat Bravo 1.4L Turbo
• 2012-2021 Fiat Panda 0.9L TwinAir Turbo
• 2008-2014 Lancia Delta III 0.9L TwinAir Turbo
• 2011-2020 Lancia Ypsilon 0.9L TwinAir Turbo

Fitment Notes

• Fits Abarth 500 models made in MEXICO (North American delivered 500 Abarths) ONLY
• Does NOT fit Abarth 595 or 695 models assembled in Italy or Poland - use Part# TS-0223-1289 instead
• Direct replacement for factory electronic diverter valve
• True plug-and-play installation - no adapters, hoses, or extra assembly required
• Plumb Back configuration recirculates all air back into intake system (quiet operation)
• For Dual Port (vent to atmosphere) version with blow-off sound, use Part# TS-0223-1084
• NOT CARB Legal - cannot ship to California

Features

• Award-winning Kompact EM Series - world's first true plug-and-play BOV upgrade
• Boost-Balance Valve Technology - the more boost you have, the better it seals
• Patented integrated pressure control channels
• Integrated proprietary high-temperature solenoid valve
• Positive seal O-ring on piston face for maximum boost holding
• Motorsport-proven billet aluminum construction
• High-temperature O-rings throughout
• Overcomes common faults of plastic factory valves
• Improved boost response and turbocharger performance
• No reference hoses or separate solenoids required
• Minimizes leakage for faster spool and target boost achievement
• Superior thermal performance

Specifications

• Part Number: TS-0223-1284
• UPC: 9329677022605
• Brand: Turbosmart
• Product Line: Kompact EM Series
• Model: VR15
• Type: Blow-Off Valve (BOV) / Diverter Valve
• Configuration: Plumb Back (Recirculating)
• Control Type: Electro-Mechanical (EM)
• Valve Design: Piston Style with Boost-Balance Technology
• Construction: Billet Aluminum
• Finish: Black Anodized
• Sealing: Positive Seal O-Ring on Piston Face
• Solenoid: Integrated High-Temperature Proprietary Design
• ECU Integration: Full OE Integration
• Installation: Plug-and-Play / Bolt-On
• USA Patent: 10,781,745
• AUS Patent: 2018253619
• CARB Legal: No (Not for Sale in California)
• Warranty: Turbosmart 1 Year Warranty

Included Components

• (1) Turbosmart Kompact EM VR15 Plumb Back Valve with Sensor Harness
• Mounting Hardware
• O-Ring
• Installation Instructions

Product Description

The Turbosmart TS-0223-1284 Kompact EM Plumb Back VR15 is a direct plug-and-play replacement for the factory diverter valve on select Abarth, Alfa Romeo, Fiat, and Lancia turbocharged vehicles. Simply unplug and unbolt the OEM valve and install the Kompact EM in its place with no adapters, hoses, or additional assembly required while retaining full OE ECU control. The patented Boost-Balance Valve Technology ensures the valve seals better as boost increases, while the positive seal O-ring on the piston face delivers maximum boost holding that plastic factory valves cannot match. The Plumb Back configuration quietly recirculates all excess pressure back into the intake system. Backed by Turbosmart's 1-year warranty.
