Skyjacker RA135 Extended Radius Arms Kit 4-6" for 83-97 Ford Ranger L4/V6

Vehicle Fitment

• 1983-1997 Ford Ranger (4WD, TTB front; 2.3L I4, 2.9L V6, 3.0L V6, 4.0L V6)
• 1984-1990 Ford Bronco II (4WD, TTB front; 2.8L V6 ('84-'85), 2.9L V6 ('86-'90))
• 1991-1994 Ford Explorer (4WD, TTB front; 4.0L V6)
• 1991-1994 Mazda Navajo (4WD, TTB front; 4.0L V6)
• 1994-1997 Mazda B4000 (4WD, TTB front; 4.0L V6)

Fitment Notes

• Front axle radius arm system for vehicles lifted approximately 4-6 inches.
• TTB 4WD only; not compatible with 2WD or SLA/IFS front suspensions.
• Not for 1998+ Ranger or 1995+ Explorer (different front suspension design).
• Designed to be used with a matching 4-6" suspension lift (does not provide lift by itself).
• Professional installation recommended; drilling is required; no welding.

Features

• Extended radius arms to improve caster correction on lifted TTB front ends
• Includes dedicated radius-arm frame brackets for proper geometry
• Transfer case crossmember included for strength and correct arm mounting
• Strut arm bushing kit (polyurethane) included for durable articulation
• Engineered specifically for 4-6 in lift heights
• Bolt-on installation with drilling; no welding to frame required
• Designed to work with OEM TTB axle beams and coil springs
• Restores on-road tracking and steering feel on lifted vehicles

Specifications

• Part Number: RA135
• System Type: Extended front radius arm kit
• Lift Compatibility: ~4-6 inches
• Front Suspension: Twin-Traction Beam (TTB)
• Drivetrain: 4WD only
• Position: Front (left and right arms)

Included Components

• 2x Extended radius arms (left & right)
• 2x Radius-arm frame brackets
• 1x Transfer case crossmember
• 1x Strut arm bushing kit (polyurethane)
• All required installation hardware
• Installation instructions

Product Description

Skyjacker's RA135 extended radius arm kit is built to correct suspension geometry on 4-6 inch lifted, TTB-equipped 4WD Ford compact trucks and their Mazda counterparts. By relocating the radius arm pivots and extending arm length, the system helps recover caster, improves on-road tracking, and enhances suspension function on lifted applications.

The kit includes model-specific radius-arm brackets, a reinforced transfer case crossmember, and a polyurethane strut arm bushing kit, delivering a comprehensive, bolt-on solution (with drilling) that integrates with OEM TTB axle beams and coil springs. Ideal for 1983-1997 Ranger, 1984-1990 Bronco II, 1991-1994 Explorer, 1991-1994 Navajo, and 1994-1997 B4000 4WD platforms.
