Radium 20-1176 Fuel Brake Line Retainer Kit for 1990-2006 BMW E36 E46 Aluminum

Vehicle Fitment

• 1990-1999 BMW E36 316i
• 1990-1998 BMW E36 318i
• 1992-1998 BMW E36 318is
• 1994-2000 BMW E36 318ti
• 1991-1998 BMW E36 320i
• 1995-1998 BMW E36 323i
• 1991-1995 BMW E36 325i
• 1995-1998 BMW E36 328i
• 1992-1999 BMW E36 M3
• 1999-2005 BMW E46 316i
• 1998-2006 BMW E46 318i
• 1998-2006 BMW E46 320i
• 1998-2000 BMW E46 323i
• 2001-2006 BMW E46 325i
• 1998-2000 BMW E46 328i
• 2000-2006 BMW E46 330i
• 2003-2006 BMW E46 330i ZHP
• 2000-2006 BMW E46 M3
• 2003-2004 BMW E46 M3 CSL

Fitment Notes

• Replaces the OEM plastic retainers that secure the factory hard lines running along the underside of the chassis.
• Compatible with 6AN (return) and 8AN (feed) Radium EFI rubber hose and Radium PTFE hose. Reference the retainer dimensions before ordering to confirm compatibility with non-Radium fuel lines.
• Aftermarket fuel lines are NOT included - this kit contains retainer clamps only.
• Designed to work in conjunction with the Radium BMW E36/E46 fuel pump hanger plumbing kits (20-1175-03 / 20-1175-05), but can be used independently for any custom fuel line installation.

Features

• CNC-machined billet 6061 aluminum construction for superior strength and corrosion resistance versus OEM plastic retainers.
• Anodized finish protects against oxidation and road exposure in the underbody environment.
• Accommodates both 6AN return and 8AN feed lines simultaneously for a clean, organized installation.
• Stainless steel mounting hardware and stainless steel line adapters included for long-term durability.
• Mounts using OEM mounting studs - no drilling or permanent modification required.

Specifications

• Material: CNC-machined anodized 6061 aluminum
• Hardware: Stainless steel
• Compatible Line Sizes: 6AN (return) and 8AN (feed)
• Mounting: OEM stud locations, no drilling required
• Quantity: 2x retainer clamps

Included Components

• 2x Anodized billet aluminum fuel/brake line retainers
• 2x Stainless steel line adapters
• Stainless steel mounting hardware

Product Description

The Radium Engineering 20-1176 is a CNC-machined billet aluminum fuel and brake line retainer kit designed to replace the OEM plastic retainers on BMW E36 and E46 vehicles. When upgrading to an aftermarket AN-style fuel system using Radium's E36/E46 fuel pump hanger plumbing kits, these retainers provide the necessary support for larger 6AN and 8AN fuel lines routed along the underside of the chassis.

Constructed from anodized 6061 aluminum with stainless steel adapters and hardware, this kit is built to outlast the factory plastic clips in demanding conditions. Installation uses the existing OEM mounting studs - no drilling or modification required. Fuel lines are sold separately; reference the published retainer dimensions to confirm compatibility with non-Radium hose choices.
