Koyo HH012170 Aluminum Radiator for 2008-2011 Lexus IS-F 5.0L V8

Vehicle Fitment

• 2008-2011 Lexus IS-F (XE20, 5.0L V8 2UR-GSE, RWD, 8-Speed Automatic)

Fitment Notes

• Race-use-only radiator configuration.
• Factory internal transmission cooler has been eliminated.
• Requires external auxiliary transmission cooler for automatic transmission operation.
• Direct-fit installation using OEM mounting locations.
• Retains compatibility with factory fan shroud and coolant hoses.

Features

• All-aluminum high-performance racing radiator construction
• Koyorad Hyper Core technology for increased cooling efficiency
• 48mm high-density two-row core design
• Hand-welded fully brazed aluminum construction
• Direct bolt-in installation with OEM-style fitment
• Designed for high-heat track and performance applications
• Billet aluminum drain and bleeder plugs
• Triple pressure-tested for durability and leak prevention
• Improved coolant capacity versus factory radiator
• Compatible with OEM fan shroud and factory coolant hoses

Specifications

• Part Number: HH012170
• Radiator Type: Hyper Core Aluminum Racing Radiator
• Core Thickness: 48mm (1.89")
• Core Configuration: Two-Row
• Material: Fully Brazed Aluminum
• Transmission Compatibility: Automatic Transmission
• Transmission Cooler: Not Included
• Engine Compatibility: 5.0L V8 2UR-GSE
• Vehicle Drivetrain: RWD
• Position: Front Engine Cooling System

Included Components

• 1x Koyorad Hyper Core Aluminum Radiator
• 1x Billet Drain Plug
• 1x Billet Bleeder Plug

Product Description

The Koyo HH012170 Hyper Core aluminum radiator is engineered specifically for the 2008-2011 Lexus IS-F equipped with the 5.0L 2UR-GSE V8 engine and automatic transmission. Designed for high-performance street and track applications, this all-aluminum radiator significantly increases cooling capacity and thermal efficiency over the factory unit while maintaining direct-fit OEM-style installation.

Built around Koyorad's proven 48mm two-row Hyper Core design, the HH012170 improves heat dissipation during aggressive driving, track sessions, and high-temperature operation. The fully brazed aluminum construction and precision hand-welded end tanks provide exceptional durability under sustained thermal stress while retaining compatibility with the factory fan shroud and OEM coolant hose routing.

To maximize cooling efficiency and eliminate the risk of fluid cross-contamination, Koyorad removed the factory integrated transmission heat exchanger from this race-use radiator design. An external transmission cooler is therefore required for automatic transmission applications. With its increased coolant capacity, billet hardware, and direct bolt-in fitment, the HH012170 is an ideal upgrade for IS-F owners seeking reliable high-performance cooling performance.
