FOX 883-06-227 Factory Race 2.5 Internal Bypass Coilovers for 03-24 4Runner & FJ

Vehicle Fitment

2003-2024 Toyota 4Runner 4WD/2WD
2007-2014 Toyota FJ Cruiser 4WD/2WD
2003-2009 Lexus GX470 4WD/2WD

Fitment Notes

• Front position only - sold as a pair
• Designed for 2-3" lift applications
• Requires aftermarket upper control arms for proper geometry
• Adjustable ride height via preload ring
• Vehicle-specific valving tuned for Toyota 4Runner/FJ Cruiser/Lexus GX platform

Features

• Patented Internal Bypass technology for multiple zones of damping control
• Velocity and position-sensitive damping for high-speed terrain capability
• Bypass bleed holes in ride zone allow oil to flow around piston for comfort
• Progressive damping force controls bottom-outs and prevents harsh top-outs
• Dual Speed Compression (DSC) adjuster for high and low speed compression tuning
• 2.5" diameter aluminum shock body with Type III anodization for corrosion resistance
• External reservoir with Internal Floating Piston (IFP) separates oil from nitrogen
• Increased oil capacity maintains consistent damping and cooler shock temperatures
• 7/8" shaft diameter with heat-treated hard chrome plated steel piston rod
• Redundant sealing system with main seal, wiper seal, and scraper seal
• High-flow 6061-T6 hard anodized billet aluminum race piston
• PTFE-lined heat-treated alloy steel spherical bearings
• Ride height preload ring for easy adjustment
• Race-proven technology developed in harshest off-road conditions

Specifications

• Brand: FOX
• Part Number: 883-06-227
• Product Line: Factory Race Series 2.5 Internal Bypass
• Position: Front
• Shock Body Diameter: 2.5"
• Shock Body Material: Aluminum
• Body Finish: Type III Anodized
• Shaft Diameter: 7/8" (0.875")
• Shaft Material: Hard Chrome Plated Steel
• Piston: 6061-T6 Hard Anodized Billet Aluminum, High-Flow
• Reservoir Type: External Remote with IFP
• Adjustment: Dual Speed Compression (DSC) + Ride Height Preload
• Compressed Length: 17.19"
• Extended Length: 22.48"
• Travel: 5.29"
• Top Mount: OEM
• Bottom Mount: Eyelet
• Lift Range: 2" - 3"
• Coil Springs: Included (Eibach 3.0 Racing Springs)
• Quantity: Pair (2 Coilovers)
• Country of Origin: USA
• Warranty: 1 Year Limited

Included Components

• 2 FOX Factory Race 2.5 Internal Bypass coilover shocks
• 2 external reservoirs with DSC adjusters
• Reservoir mounting brackets
• Spherical bearings
• Mounting hardware

Product Description

The FOX 883-06-227 Factory Race Series 2.5 Internal Bypass Coilover delivers race-proven, high-speed capable suspension for 2003-2024 Toyota 4Runner, 2007-2014 FJ Cruiser, and 2003-2009 Lexus GX470 platforms with 2-3" lift. FOX's patented Internal Bypass technology creates multiple zones of damping control--shock fluid bypasses the main piston through bleed holes in the ride zone for comfort, then as the shock travels past this zone the holes terminate, forcing oil through the piston for progressive damping that controls hard bottom-outs and prevents harsh top-outs. The Dual Speed Compression adjuster allows fine-tuning for load, terrain, and driving style, while the 2.5" Type III anodized aluminum body and external reservoir maintain consistent damping and cooler operating temperatures for fade-free performance in demanding off-road conditions.
