fifteen52 AHDAB-78069+25 Analog HD 17x8 6x139.7 +25mm Asphalt Black Wheel Each

Vehicle Fitment

• 6x139.7 (6x5.5") bolt pattern - fits all vehicles using this bolt pattern with a compatible hub bore of 106.2mm or larger (with appropriate hub centric rings if needed)
• Common confirmed fitments include: Chevrolet Silverado 1500/2500/3500 (1999+), Chevrolet Suburban (1960+), Chevrolet Tahoe (1995+), Ford Bronco (1966-1977 and 2021+), Ford Ranger (1983+), Isuzu Trooper (1986-2002), Mitsubishi Montero / Pajero, Toyota 4Runner, Toyota Tacoma, Toyota Tundra (first gen), Toyota Land Cruiser, and other Toyota/Lexus 6x139.7 applications
• Note: Fitment is determined by bolt pattern, hub bore, offset, and brake/suspension clearance. Always verify fitment for your specific year, make, model, and trim - especially if running leveling kits, lift kits, upgraded brake calipers, or aftermarket suspension components that may affect clearance.

Fitment Notes

• Sold as a single wheel (each). Four wheels are required for a complete set.
• Offset: +25mm. Backspacing: 5.5". These measurements determine how far the wheel sits inside or outside the wheel well. Verify these against your vehicle's minimum and maximum offset tolerance before ordering, particularly if running a lift or leveling kit - changes in ride height affect available clearance both inboard and outboard.
• Hub bore is 106.2mm. Most 6x139.7 trucks and SUVs have hub bores between 78mm and 110mm. If your vehicle's hub bore is smaller than 106.2mm, hub centric rings will be required for proper centering. If your vehicle's hub bore is larger than 106.2mm, these wheels will not center on the hub and should not be used without appropriate adapters.
• TPMS compatible - designed to accept factory TPMS sensors and standard valve stems. If your vehicle has factory TPMS, retain your existing TPMS sensors and transfer them to the new wheels. Fifteen52 aluminum valve stems are available separately for a custom appearance upgrade.
• Lug seat type: Verify lug nut seat type (conical/tapered vs. ball seat vs. flat) for your specific vehicle before selecting lug nuts. Aftermarket wheels typically require aftermarket lug nuts - confirm seat type and thread pitch.

Features

• Analog HD design - the Analog HD is fifteen52's modern aluminum interpretation of the classic steel steelie wheel that was common on utility trucks and off-road vehicles of the 1960s-1980s. The design retains the clean, unadorned aesthetic of the original steel steelie - flat face, minimal surfacing, utilitarian character - while incorporating contemporary engineering refinements, lighter materials, and functional updates that improve on the original in every measurable way.
• All-aluminum one-piece cast construction - replacing steel with aluminum reduces unsprung rotational weight compared to a comparably sized steel wheel. Lower unsprung weight improves suspension response, reduces the rotational inertia that the drivetrain and brakes must manage, and decreases the gyroscopic forces that affect steering feel at highway speeds. At 29.48 lbs for a 17x8 in this bolt pattern, the Analog HD delivers steelie aesthetics with the weight advantage of cast aluminum.
• Slotted brake cooling pockets - the recessed center section geometry directs airflow through slotted openings toward the brake hub area while the vehicle is in motion, providing passive brake cooling that is particularly beneficial in off-road applications involving sustained descents, towing, or repeated braking cycles where brake temperature management is important.
• Reinforced flange design - the outer wheel lip is engineered with added structural reinforcement to resist deformation from the rock, curb, and trail impacts that characterize the applications these wheels are designed for. The reinforced flange protects bead integrity and wheel geometry in the impact zones most commonly damaged during off-road use.
• Concave lug area with exposed lugs - the lug boss area is recessed and the lugs sit exposed in the wheel face rather than behind a cap or cover, providing an intentional visual callback to period-correct utility wheel aesthetics while simplifying lug nut access during tire changes.
• Engraved branding and specifications - size, offset, and fifteen52 branding are engraved directly into the wheel face rather than applied as stickers or paint fill, providing permanent identification that survives cleaning and trail exposure without degradation.
• 2,650 lb load rating - the per-wheel load rating of 2,650 lbs supports the weight demands of full-size trucks and body-on-frame SUVs that constitute the primary fitment for the 6x139.7 bolt pattern.

Specifications

• Part Number: AHDAB-78069+25
• Model: Analog HD
• Finish: Asphalt Black
• Diameter: 17"
• Width: 8.0"
• Bolt Pattern: 6x139.7 (6x5.5")
• Offset: +25mm
• Backspacing: 5.5"
• Hub Bore: 106.2mm
• Weight: 29.48 lbs
• Load Rating: 2,650 lbs per wheel
• Construction: One-piece cast aluminum
• TPMS: Compatible (accepts factory TPMS sensors and standard valve stems)
• Sold As: Each (single wheel)
• Warranty: Lifetime structural / 1-year finish

Included Components

• 1x fifteen52 Analog HD 17x8.0 +25mm Asphalt Black wheel
• Note: Tires, lug nuts, TPMS sensors, valve stems, and hub centric rings are NOT included. Four wheels are required for a complete set.

Product Description

The fifteen52 AHDAB-78069+25 is a single Analog HD 17x8.0 wheel in Asphalt Black, sized in a 6x139.7 (6x5.5") bolt pattern with +25mm offset, 5.5" backspacing, and a 106.2mm hub bore, with a 2,650 lb per-wheel load rating. The Analog HD is fifteen52's aluminum reinterpretation of the classic steel steelie - retaining the flat-faced, minimal, utilitarian character of the original utility wheel design while replacing steel construction with cast aluminum and incorporating functional updates including slotted brake cooling pockets, a reinforced outer flange, and engraved branding.

The one-piece cast aluminum construction reduces unsprung weight compared to a steel equivalent at the same size, contributing to improved suspension response and reduced rotational inertia across the 6x139.7 full-size truck and SUV applications this wheel targets. The Asphalt Black finish is a semi-gloss dark treatment that coordinates with OEM and aftermarket black trim, bumpers, and skid plates common on off-road builds in the Silverado, Tahoe, Suburban, Tacoma, 4Runner, Tundra, and Bronco platforms. The exposed-lug concave center section with slotted cooling pockets delivers the utilitarian appearance of a period-correct steelie while improving airflow to the brake assembly.

The AHDAB-78069+25 is covered by fifteen52's limited lifetime structural warranty against defects in materials and workmanship, and a one-year finish warranty from the original date of purchase. The finish warranty excludes damage from road salt, improper cleaning agents, after-sale refinishing, off-road or track use, improper tire mounting, use of clip-on balance weights, and installation errors. Wheels are sold individually - four are required for a complete vehicle fitment.
