Brembo 09.5373.20 Vented Front Rotor for Mercedes 300SL 500SL 500E SL320 SL500

Vehicle Fitment

• 1990-1993 Mercedes-Benz 300SL (R129, 3.0L I6)
• 1990-1993 Mercedes-Benz 500SL (R129, 5.0L V8)
• 1992-1993 Mercedes-Benz 500E (W124, 5.0L V8)
• 1994 Mercedes-Benz E500 (W124, 5.0L V8)
• 1994-1997 Mercedes-Benz SL320 (R129, 3.2L I6)
• 1994-1996 Mercedes-Benz SL500 (R129, 5.0L V8, Standard 300mm Front Brake Configuration)

Fitment Notes

• Front axle fitment only - sold as a set of 2 rotors per box
• Applies to R129 SL-Class and W124 E-Class models equipped with the standard 300mm front brake configuration; not all vehicles in these ranges used the same front rotor size - confirm your vehicle's front rotor diameter before ordering
• 1993 Mercedes-Benz 500E: applies to chassis serial numbers through B930494 only; vehicles above this serial number may use a different front rotor specification
• 1994-1996 SL500 with standard (non-enlarged) front rotors only; some R129 models fitted with the AMG or sport brake upgrade used a larger front rotor
• 300SL fitment applies to vehicles without ASR (traction control); ASR-equipped models may have a different front brake specification
• Mercedes-Benz OE cross-references: A1294212012, 1294210612

Features

• Vented disc design promotes airflow between rotor faces for improved heat dissipation under repeated braking
• High-carbon cast iron construction minimizes brake noise and vibration for smooth, refined braking on these classic Mercedes platforms
• ECE-R90 certified - meets European safety standards for replacement brake discs
• Direct OE-equivalent replacement - interchangeable with original equipment with no modifications required
• Protective surface treatment on non-friction surfaces guards against corrosion during storage and early service life
• Electronically balanced to tight tolerances, minimizing runout and pedal pulsation
• Intelligent minimum thickness marking for quick wear monitoring at service intervals
• Includes fixing screw kit with all hardware required for installation

Specifications

• Position: Front (Left and Right)
• Disc Type: Vented
• Outside Diameter: 300 mm (11.81 in)
• Nominal Thickness: 28 mm
• Minimum Thickness: 25.4 mm
• Overall Height: 46 mm
• Center Bore: 67 mm
• Lug Hole Count: 5
• Tightening Torque: 120 Nm
• Surface Finish: Standard (Non-UV Coated)
• Material: High-Carbon Gray Cast Iron
• ABS Tone Ring: Not Included
• Mercedes-Benz OE Cross-References: A1294212012, 1294210612
• Brembo Line: Prime (OE Replacement)

Included Components

• 2x Brembo Vented Front Brake Rotors
• 1x Fixing Screw Kit (all mounting hardware included)

Product Description

The Brembo 09.5373.20 is a vented front brake rotor from the Brembo Prime line, designed for the Mercedes-Benz R129 SL-Class (300SL, 500SL, SL320, SL500) and W124 E-Class (500E, E500) models equipped with the standard 300mm front brake configuration. It cross-references Mercedes-Benz OE part numbers A1294212012 and 1294210612, and installs as a direct bolt-on with no modifications required. Both front rotors are included per box.

This part carries the Brembo ".20" suffix, indicating a standard (non-UV) coated finish - the protective treatment on non-braking surfaces provides corrosion resistance during storage and initial service without the full UV paint process of the ".11" series. High-carbon cast iron alloy reduces the noise and vibration typical of economy-grade replacements. ECE-R90 certified. Important: the 300mm front rotor applies only to R129 and W124 vehicles with the standard brake setup. Some 500E/E500 vehicles above chassis serial B930494, later SL500 models, and any R129 equipped with enlarged front brakes will require a different part - confirm your vehicle's front rotor diameter before ordering.
