Old Man Emu CS036R Rear 2.5" Lift Medium Load Leaf Spring 87-95 Jeep Wrangler YJ

Vehicle Fitment

• 1987-1995 Jeep Wrangler YJ (2.5L I4 / 4.0L I6, 4WD)

Features

• Provides approximately 2.5" (63.5mm) of rear lift for enhanced ground clearance
• Medium load capacity suitable for vehicles with hard tops or additional accessories
• Draw-tapered and diamond-cut leaves distribute loads evenly, reducing stress
• Bolted leaf clamps allow installation of anti-squeak nylon liners
• Fully scragged to minimize the risk of sagging over time
• Load tested to ensure the spring meets the required specification
• Military wrap design offers added safety in case of main leaf failure
• Re-greasable nylon interleaf anti-friction pads reduce friction at leaf tips
• Flat axle seat area ensures a positive, safe axle mount and reduces spring stress
• Shot peened to reduce spring stress and increase spring life
• Two-stage leaf pack provides a balance between comfort and load-carrying capacity

Specifications

• Part Number: CS036R
• Position: Rear
• Lift Height: Approximately 2.5" (63.5mm)
• Load Rating: Medium Load (up to 200 kg)
• Number of Leaves: 5
• Spring Rate: 188 lbf/in
• Primary Free Camber: 205mm
• Eye Diameter: 37.5mm (Front) / 31.5mm (Rear)
• Stack Height: 32.5mm
• Weight: 13.7 kg (30.2 lbs)
• Material: High-quality steel
• Finish: Black powder-coated
• Warranty: 3 years

Included Components

• One (1) Old Man Emu CS036R rear leaf spring
• Pre-installed anti-friction pads and bolted clamps
• Installation instructions

Product Description

The Old Man Emu CS036R Rear Leaf Spring is engineered to enhance the suspension performance of your 1987-1995 Jeep Wrangler YJ. Designed to provide approximately 2.5 inches (63.5mm) of lift, this leaf spring improves ground clearance and load-carrying capacity, making it ideal for both recreational off-roading and commercial use.

Constructed with high-quality steel and featuring a progressive spring rate of 188 lbf/in, the CS036R offers a comfortable ride when unladen and additional support when carrying moderate loads. Its design includes draw-tapered and diamond-cut leaves, bolted clamps, and re-greasable anti-friction pads, contributing to its durability and longevity.

Whether you're navigating rugged terrains or hauling equipment, the Old Man Emu CS036R Rear Leaf Spring delivers reliable performance and improved handling, making it a valuable upgrade for your Wrangler's suspension system.
