Wiseco K567M84AP Forged 84 mm +2 cc Pistons for Honda B-Series

Vehicle Fitment

• Honda B16A (Civic / Integra, 1.6 L)
• Honda B20B / B20Z (with VTEC head)
• Honda CR-V / other B-series compatible builds (97-02)

Features

• Forged from 2618 aluminum for high strength and durability
• ArmorPlating (or ArmorGlide) skirt coating to reduce friction and wear
• +2 cc positive-dome design to increase compression
• Strutted forging for additional rigidity under high load
• Precision CNC-machined crown with optimized valve reliefs
• Forced-pin oiling for reliable lubrication at high RPM
• Performance piston ring set included
• 21 mm wrist pin for strong and stable connection

Specifications

• Bore: 84.00 mm
• Compression Height: 30.00 mm
• Dome Volume: +2.0 cc
• Wrist Pin Diameter: 21 mm
• Material: Forged 2618 alloy
• Piston Weight: ~288 g each
• Ring Set: 8400XX
• Compression Ratio: ~11.3:1 (with B20B / B16A VTEC head)

Included Components

• 4x forged pistons (84 mm, +2 cc dome)
• 4x 21 mm wrist pins
• 4x circlips / locks for wrist pins
• 4x high-performance piston ring sets (8400XX)

Product Description

The Wiseco K567M84AP is a high-performance forged piston kit designed for Honda B-series builds, especially hybrid setups like a B20B block with a B16A VTEC head. With an 84 mm bore and a +2 cc dome, this kit delivers a strong compression boost (~11.3:1) while maintaining durability and reliability.

These pistons are made from lightweight yet robust 2618 aluminum and feature strutted forging for increased structural strength. The ArmorPlating on the skirts (or ArmorGlide) reduces friction and wear under high-RPM operation. Combined with a matched ring set and 21 mm wrist pins, these pistons give you solid sealing and stable performance.

Installation requires checking piston-to-wall clearance, ring gap, and deck height. Because of the raised dome, choose an appropriate head gasket thickness to optimize compression for your specific build. This kit is ideal for high-compression, naturally aspirated, or mildly tuned B-series engines.
