Wilwood 140-10776-DR FNSL6R 6-Piston Front Hub Kit Drilled 14" for 1963-87 C10

Regular price: $2,564.31
Regular price: ~~$2,872.03~~
Sale price: $2,564.31

Shipping calculated at checkout.

In Stock: 2

Orders by 1pm PST ship same business day

Free Shipping w/3-4 Day Delivery

Authorized Dealer

Fitment Guarantee

30-Day Hassle Free Returns

Product Specification:

SKU:WIL140-10776-DR

MPN: 140-10776-DR

UPC: 889545010404

Weight: 73.5 lb

Inventory: 2

Type: Big Brake Kits

Vehicle Fitment

1963-1987 Chevrolet/GMC C10/C15, R10, Suburban and GMC Jimmy with CPP or Ridetech 2" drop spindles (5-lug)
Fit confirmed through GM C/K series fitment with specified drop spindles; not compatible with stock spindles
Official coverage ends 1987; 1988 and newer C/K requires further validation

Features

Forged Narrow Superlite 6R billet aluminum radial-mount calipers (red)
14.00" vented Spec-37 drilled & slotted rotors with SRP finish
Hat offset ~1.62" for proper spindle clearance
Stainless steel pistons for heat and corrosion resistance
BP-10 high-friction brake pads included
Radial mount improves stiffness and pad contact consistency
Kit developed for drop spindle spindles from CPP and Ridetech exclusively
Requires 17" or larger wheels for proper clearance

Specifications

Rotor: 14.00" x 1.25" (vented, drilled/slotted)
Piston area: ≈ 4.04 sq in; pad area: ≈ 8.20 sq in
Bolt pattern: 5x4.75" or 5x5.00"
Hat offset: ~1.62"; hub pattern: dual drilled
Mount: Radial, FNSL6R calipers, stainless pistons, spec-37 iron rotors
Position: Front only; no parking brake provision

Included Components

2x Forged 6-piston FNSL6R front calipers (red)
2x 14" drilled/slotted vented rotors (Spec-37 iron)
2x aluminum rotor hats (1.62" offset, red hardware)
Mounting hardware kit (brackets, bolts, hub components)
2x BP-10 brake pads pre-installed

Product Description

The Wilwood 140-10776-DR kit equips vintage GM C10/C15/R10 trucks, Suburbans, and GMC Jimmys (1963-1987) with modern, high-performance braking. Featuring forged red FNSL6R six-piston radial calipers and 14" drilled/slotted Spec-37 rotors, this system delivers improved stopping power and heat management while maintaining factory-style brake bias with drop-spindle setups.

Engineered exclusively for use with CPP or Ridetech 2" drop spindles, the kit fits directly to existing setups using 5-lug hubs. The rotor hats have 1.62" offset and require 17"+ wheels for clearance. Installation is direct bolt-on with included hardware and performance BP-10 brake pads. Note: only front axle; no rear or parking brake feature included. Fitment is officially confirmed through 1987; any model year beyond that must be verified separately.
