Whiteline W53485 Front Lower Arm Bushing for 2010-16 Hyundai ix35 Kia Sportage

Vehicle Fitment

• 2010-2013 Hyundai i45 (YF, Active, Elite, Premium - 2.0L G4KD I4, 2.4L G4KJ I4, FWD)
• 2010-2015 Hyundai ix35 (LM - Active, Elite, Highlander, SE - 2.0L G4KD I4, 2.4L G4KE/G4KJ I4, FWD/AWD)
• 2010-2016 Kia Sportage (SL - Si, Si Premium, SLi, Platinum - 2.0L G4KD I4, 2.4L G4KE/G4KJ I4, FWD/AWD)

Fitment Notes

• Fitting position: Front Lower Control Arm - Inner Rearward
• Standard alignment replacement bushing - does not alter caster angle (see KCA502 for caster correction)
• Wheel alignment required after installation (Front)
• Installation difficulty: Suspension specialist recommended; estimated install time 4 hours
• No crush tubes included - shell bushing design only

Features

• Advanced synthetic elastomer formula delivers superior elasticity, memory retention, and long-term durability across all driving applications
• Outperforms OEM rubber bushings - resists oil, grease, ozone, and weathering for a longer service life
• Restores vehicle stability, steering precision, and braking efficiency lost from worn factory bushings
• Delivers a balanced mix of ride comfort at lower speeds and firm chassis control under cornering, braking, and acceleration loads
• Shell-type construction with internal bore knurling for a secure, precise press fit into the control arm housing
• Protective coating on all metal components resists corrosion and extends overall service life
• Designed to minimize the need for specialized tools during installation
• Backed by Whiteline's Limited Lifetime Warranty

Specifications

• Part Number: W53485
• Fitting Position: Front Lower Control Arm - Inner Rearward
• Bushing Type: Type 16 - Shell Without Flange
• Outer Diameter (A): 69.8 mm
• Inner Diameter (B): 14.2 mm
• Length (C): 60.0 mm
• Flange Thickness (D): 12 mm
• Flange OD (E): 35 mm
• Crush Tubes: Not included
• Warranty: Limited Lifetime

Included Components

• 2x Synthetic Elastomer Shell Bushings

Product Description

The Whiteline W53485 is a front lower control arm inner rearward bushing kit engineered for the 2010-2013 Hyundai i45 (YF), 2010-2015 Hyundai ix35 (LM), and 2010-2016 Kia Sportage (SL). Worn front control arm bushings are a leading cause of steering vagueness, brake dive, and front-end instability - particularly on vehicles with higher mileage. This kit replaces the factory rubber inner rear bushings with Whiteline's advanced synthetic elastomer compound, restoring proper front suspension geometry and significantly improving vehicle control.

Whiteline's synthetic elastomer provides a balanced performance profile: compliant and comfortable at everyday driving speeds, yet firm and responsive under hard cornering, braking, or acceleration. The shell-style design requires a hydraulic press for installation and a front wheel alignment upon completion. A suspension specialist is recommended due to the estimated 4-hour installation time and the precision required to correctly seat the shell bushings in the control arm housing.
