Weld S90870067P49 Belmont Beadlock 17x10 5x114.3 +49 Gloss Black Milled Mustang

Vehicle Fitment

• 2005-2014 Ford Mustang V6 / GT (S197 - All Trims)
• 2015-2023 Ford Mustang GT / EcoBoost / V6 (S550 - All Trims)
• 2015-2020 Ford Mustang Shelby GT350 (S550 - All Trims)
• 2024-2025 Ford Mustang GT / EcoBoost (S650 - GT and EcoBoost trims, non-Performance Pack, non-Dark Horse only)
• 1979-1993 Ford Mustang FoxBody (All Trims)
• 1994-2004 Ford Mustang V6 / GT / Mach 1 / Cobra / Bullitt (All Trims)
• 1993-2002 Toyota Supra MK4 (All Trims)
• Universal - fits any vehicle with a 5x114.3mm (5x4.5") bolt pattern. Verify hub bore, offset, and brake clearance before ordering.

Fitment Notes

• Bolt Pattern: 5x114.3mm (5x4.5")
• Offset: +49mm / Backspace: 7.40" - verify fitment for your specific suspension, brake package, and wheel well configuration before ordering.
• 2024+ S650 Mustang Performance Pack and Dark Horse: this wheel does NOT clear the brakes - those trims require the 18x10 +45mm offset Belmont Beadlock variant. Do not order for these trims.
• This part number (S90870067P49) supersedes the previous S90870067P50 (ET50 / 7.50" backspace).
• Hub Bore: 78.1mm - hub-centric rings may be required for vehicles with a larger hub bore. Hub-centric ring compatible.
• This wheel features a functional (real) beadlock ring - verify local sanctioning body regulations before use in sanctioned competition, as beadlock wheels may have class-specific restrictions.
• Exposed lug design - lug nuts are NOT included and must be purchased separately. Requires 60° conical seat lug nuts.
• Drag strip use - trial fit before mounting tires.
• Sold individually (one wheel per listing).

Features

• Belmont Beadlock S908 - traditional, timeless spoke styling engineered for serious Mustang drag racing, combining full beadlock technology with Weld's proven rotary forged construction.
• Real functional 6061 forged aluminum beadlock ring with Heli-Coil thread inserts mechanically clamps the tire bead to the rim, preventing de-beading at low tire pressures under hard launches.
• Inner and outer barrel bead knurling provides an additional layer of mechanical tire bead retention.
• Rotary forged monoblock aluminum construction delivers improved rigidity and reduced rotating mass - optimized for Mustang drag racing performance.
• Gloss Black milled center and beadlock ring finish with a mirror polished lip and clearcoat protection for a bold, race-ready multi-tone appearance.
• 17x10" with +49mm offset provides a wide rear traction footprint optimized for the Mustang platform across all generations including FoxBody through S650.
• TPMS sensor compatible.
• Hub-centric ring compatible.
• Center cap included.
• Lifetime structural warranty and 1-year finish warranty from Weld Performance.

Specifications

• Part Number: S90870067P49 (supersedes S90870067P50)
• Series: Weld Performance Belmont Beadlock S908
• Diameter: 17"
• Width: 10"
• Bolt Pattern: 5x114.3mm (5x4.5")
• Offset: +49mm
• Backspacing: 7.40"
• Hub Bore: 78.1mm
• Finish: Gloss Black Milled Center & Beadlock Ring / Mirror Polish Lip with Clearcoat
• Beadlock: Real / Functional - 6061 forged aluminum beadlock ring with Heli-Coil inserts
• Bead Knurling: Yes - inner and outer barrel
• Construction: Rotary forged monoblock aluminum
• Lug Style: Exposed lugs
• Lug Nut Seat: 60° Conical
• Lug Nuts Included: No
• Center Cap Included: Yes
• TPMS Compatible: Yes
• Hub-Centric Ring Compatible: Yes
• Quantity: Sold individually

Included Components

• 1x Weld Performance Belmont Beadlock S908 17x10 wheel with real beadlock ring (Gloss Black Milled with Mirror Polish Lip)
• 1x Center cap

Product Description

The Weld S90870067P49 is the Belmont Beadlock S908 Series 17x10 rotary forged drag racing wheel with a real functional beadlock for 5x114.3mm (5x4.5") bolt pattern Mustangs and other compatible performance cars. This is the updated part number, superseding the previous S90870067P50 (ET50 / 7.50" BS), with revised geometry at +49mm offset and 7.40" backspace for improved Mustang platform fitment compatibility across generations from FoxBody through the 2024+ S650.

The real 6061 forged aluminum beadlock ring with Heli-Coil thread inserts locks the tire bead mechanically, while inner and outer barrel bead knurling adds a secondary layer of retention under hard launches. The Belmont's traditional spoke design carries a timeless aesthetic that pairs well with classic and modern Mustang builds alike. Critical fitment note: 2024+ S650 Performance Pack and Dark Horse trims require the 18x10 +45mm offset Belmont Beadlock variant - this wheel does not clear those brake packages. Beadlock wheels may have class-specific restrictions in sanctioned drag racing - verify regulations before competition use. Trial fit before mounting tires. Lug nuts not included. Center cap included. TPMS compatible. Backed by Weld Performance's lifetime structural warranty and 1-year finish warranty. Sold individually.
