Ticon 903-03021-1000 3.0in Titanium V-Band Clamp Kit CP1 TIG Welding Flange Set

Vehicle Fitment

• Universal Fabrication Component. Designed for welding to 3.0-inch (76.2mm) O.D. titanium tubing, typically used in exhaust, downpipe, and turbocharger applications.

Fitment Notes

• Requires TIG welding for installation. Use of back-purging is highly recommended, as with all titanium welding.
• Designed specifically for 3.0-inch O.D. tubing; not compatible with larger or smaller diameters.
• Flange mating surfaces must be kept clean and free of contamination to ensure a proper seal.

Features

• Manufactured from lightweight and high-strength Grade 1 (CP1) commercially pure Titanium.
• V-band design provides a high-integrity, leak-free, and quick-release connection for easy component removal.
• The CP1 Titanium construction offers superior corrosion resistance compared to stainless steel.
• Retains joint integrity and clamping force even under extreme temperature cycling typical of turbo exhaust systems.
• Both male and female interlocking flanges ensure precise alignment every time the connection is reassembled .
• Ideal for creating modular connections in high-performance exhaust, downpipe, and wastegate dump tube fabrication.
• Flanges feature a precision-machined weld lip for optimal TIG welding integration.
• Titanium assembly significantly reduces weight compared to equivalent stainless steel V-band kits.

Specifications

• Part Position: Universal Exhaust/Turbo Connection
• Material: Commercially Pure Grade 1 (CP1) Titanium
• Tube Compatibility: 3.0-inch O.D. (76.2mm)
• Clamp Material: Stainless Steel (High-Strength)
• Flange Style: Male/Female Interlocking
• Weld Requirement: TIG Welding

Included Components

• 1x 3.0-inch O.D. Male Titanium V-Band Flange
• 1x 3.0-inch O.D. Female Titanium V-Band Flange
• 1x High-Strength Stainless Steel V-Band Clamp

Product Description

The Ticon Industries 903-03021-1000 3.0in Titanium V-Band Clamp Kit is a professional-grade solution for joining 3.0-inch O.D. tubing in demanding, high-performance applications. Manufactured from Grade 1 (CP1) Commercially Pure Titanium, this kit provides a drastic weight reduction over traditional stainless steel components while offering superior corrosion and heat resistance. Titanium's exceptional material properties make this V-band kit a perfect choice for use in high-heat zones such as turbocharger downpipes, connecting exhaust sections, or wastegate setups.

The core of this system is the precision-machined interlocking male and female flange design. This feature ensures that the two pipes align perfectly every single time, minimizing the potential for leaks and simplifying component installation and removal. The V-band clamp itself, made from high-strength stainless steel for maximum clamping force, secures the flanges tightly, guaranteeing a leak-free seal even through repeated thermal cycles and high vibration.

Installation requires TIG welding the titanium flanges to the corresponding 3.0-inch O.D. pipe. Due to the sensitive nature of titanium, correct welding procedures, including thorough back-purging, are critical to maintain the material's integrity and strength. This universal kit is indispensable for fabricators looking to build the lightest, most durable, and highest-quality modular exhaust and turbo systems.
