Ticon 109-07602-0013 3.0in Titanium 90 Degree Mandrel Bend CP1 .049 Wall

Vehicle Fitment

• Universal Fabrication Component. Designed for creating 90-degree turns in custom exhaust, downpipe, turbo discharge, and intake piping using 3.0-inch O.D. titanium tubing.

Fitment Notes

• Requires professional TIG welding for integration. Argon back-purging is mandatory for welding Grade 1 Titanium to prevent weld contamination and maintain material integrity.
• Must be cut and trimmed to the specific length and orientation required for the custom application.
• The 4.5" Centerline Radius (CLR) provides an excellent balance of flow efficiency and space utilization.

Features

• Constructed from ultra-lightweight and high-strength Commercially Pure Grade 1 (CP1) Titanium.
• Precisely Mandrel-bent to a 90-degree angle, ensuring a constant internal diameter throughout the arc for non-restrictive flow.
• Features a robust 0.049-inch (1.25mm) wall thickness for increased rigidity, durability, and a more pleasant exhaust note compared to thinner gauges.
• 4.5-inch Centerline Radius (CLR) provides a smooth, gradual transition, optimizing flow velocity and minimizing turbulence.
• Titanium material provides exceptional resistance to high-heat fatigue, corrosion, and rust common in exhaust systems.
• Ideal for creating strong, high-quality angular connections that offer superior weight savings over stainless steel.
• CP1 is highly ductile and offers excellent weldability when proper inert gas shielding is employed.
• Provides the base component for building professional, high-end, high-flow custom piping systems.

Specifications

• Part Position: Universal Tubing Component
• Material: Commercially Pure Grade 1 (CP1) Titanium
• Outer Diameter (O.D.): 3.0 inches (76.2mm)
• Wall Thickness: 0.049 inches (1.25mm)
• Bend Angle: 90 Degrees
• Centerline Radius (CLR): 4.5 inches (114.3mm)

Included Components

• 1x 3.0" O.D. x 90 Degree Titanium Mandrel Bend

Product Description

The Ticon Industries 109-07602-0013 Titanium 90 Degree Mandrel Bend is an essential component for fabricators designing high-performance systems where maximum strength and minimum weight are critical. Manufactured from Commercially Pure Grade 1 (CP1) Titanium, this bend features a robust 0.049-inch wall thickness, offering excellent rigidity and durability while still being significantly lighter than comparable steel. The bend is precisely formed using a mandrel process, which guarantees that the 3.0-inch O.D. tubing maintains its full, round internal diameter, eliminating flow restrictions and turbulence in the 90-degree turn.

The 4.5-inch Centerline Radius (CLR) ensures a high-flowing, smooth path for exhaust gases or air, making it ideal for the critical connections found in turbocharger systems, such as the downpipe or intercooler piping. For successful integration, professional TIG welding is required. Due to the properties of CP1 Titanium, it is absolutely critical that **argon back-purging** is used during the welding process to shield the molten titanium from atmospheric oxygen, which is necessary to maintain the material's strength, longevity, and inherent corrosion resistance.

This universal component provides a superior foundation for creating accurate, strong, and ultra-lightweight angular changes in custom piping systems, meeting the demanding standards of motorsport and high-end fabrication.
