Snow Performance SNF-52700H Triple-Pump Fuel Hat for 2005-2019 Chevy Silverado

Vehicle Fitment

• 2005-2019 Chevrolet Silverado 1500 (Half-Ton; LS/LT/LTZ/SS/High Country/RST/Custom/WT/XFE/Hybrid), 4.3L-6.2L V8, return-style
• 2005-2019 GMC Sierra 1500 (AT4/Denali/Elevation/SLE/SLT/WT/XFE/Hybrid), 4.3L-6.2L V8, return-style

Features

• Billet aluminum fuel hat manifold with CNC-machined internal passages
• Triple-pump configuration (supports two 470 LPH and one 450 LPH TI Automotive pumps)
• Eliminates hoses, clamps and fittings - direct drop-in hat replaces factory bucket
• Viton O-rings for chemical resistance and leak-free sealing
• Black hard-anodized finish for corrosion and fuel-blend durability
• Compatible with E85, E10, and straight gasoline (not compatible with methanol)
• Female 10AN ORB feed and 8AN ORB return ports; swivel fittings sold separately
• Supports return-style fuel systems only - no returnless install

Specifications

• Material: 6061 billet aluminum, black anodized
• Pumps: TI Automotive genuine - 450 LPH and two 470 LPH units
• Port fittings: 10AN ORB feed, 8AN ORB return ports
• Flow capacity: ~1390 LPH total; supports ~1500+ RWHP on E85, ~2000 RWHP on gasoline
• Fitment: direct replacement for factory fuel hat bucket on GM half-ton return-style fuel tanks
• Weight: approx. 8-10 lb (depending on configuration)
• Emissions: Not CARB-legal (cannot be sold in California or CARB states)
• Manufactured in USA, compatible with OE EVAP, fuel level sender, filler neck

Included Components

• 1x Snow Performance SNF-52700H billet fuel hat manifold
• 3x TI Automotive fuel pumps (two 470 LPH, one 450 LPH)
• 3x Viton O-ring seals
• Mounting hardware and internal manifold fittings

Product Description

The Snow Performance SNF-52700H Triple-Pump Fuel Hat is a fully engineered, drop-in replacement for the stock fuel bucket on 2005-2019 Chevy Silverado 1500 and GMC Sierra 1500 with return-style fuel systems. Using a precision CNC-machined billet aluminum manifold and high-flow TI Automotive pumps, this hat eliminates the need for external hoses, clamps, and T-fittings, delivering a reliable sealed fuel delivery upgrade built for high-performance demands.

The triple-pump setup (two 470 LPH + one 450 LPH) supports exceptionally high horsepower requirements - capable of approximately 1500 rwhp on E85 and up to 2000 rwhp on gasoline. The assembly retains critical OE components such as the fuel level sender, EVAP system, and filler neck, while requiring a return-style fuel system only. Designed for durability, it features Viton seals and a robust black anodized finish compatible with ethanol blends. Warning: not CARB compliant and not legal for sale in CA or CARB states.

Installation is straightforward - with exact-fit compatibility to factory mounting points, the unit drops directly into the tank and bolts to OEM tabs. This makes it an ideal upgrade for truck enthusiasts building high-power, E85 or boosted fuel systems. Snow Performance backs it with their build-quality reliability and supports it with compatible fitting adapters sold separately.
