Rigid Industries 20641 Ignite Backup LED Light Kit Flush Mount Diffused Pair

Vehicle Fitment

• Universal - compatible with cars, trucks, SUVs, Jeeps, motorcycles, UTVs, and marine applications
• Designed as a backup light kit; also suitable for auxiliary reverse, work, or accent lighting applications

Fitment Notes

• Flush mount installation - requires a 1.75-inch diameter hole for recessed mounting
• Sold as a pair (2 lights)
• Wiring harness is NOT included - each light draws less than 1 amp, making them compatible with tapping directly into the vehicle's existing backup light circuit
• Input voltage range: 6-28V DC - compatible with 12V and 24V systems
• Mounting brackets and related hardware included

Features

• Diffused flood beam optics - delivers wide, even light spread ideal for backup and close-range illumination
• Rigid's smallest forward-projecting LED light - measures just 1.4 inches x 1.4 inches x 2 inches for installation in extremely tight spaces
• 1,000 raw lumens per light from a single high-output LED, drawing less than 1 amp each
• IP68 rated - fully dust-tight and rated for submersion, suitable for marine and off-road use
• UV-resistant black powder-coat finish on the housing
• Impact-resistant polycarbonate lens for protection against debris and impacts
• Over/under voltage protection, RFI/EMI protection, and reverse polarity protection
• 50,000+ hour LED lifespan
• Instant on/off - no warm-up time required
• Designed, engineered, and assembled in the USA
• Backed by Rigid Industries' Limited Lifetime Warranty

Specifications

• Part Number: 20641
• Series: Ignite
• Mount Type: Flush Mount (requires 1.75-inch hole)
• Beam Pattern: Diffused Flood
• Housing Color: Black
• Housing Dimensions: 1.4 inches x 1.4 inches x 2 inches
• LED Count: 1 per light
• Wattage: 12W per light
• Amp Draw: Less than 1A per light
• Raw Lumens: 1,000 lm per light
• Lux @ 10m: 9
• Beam Distance (1 lux): 29m
• Beam Distance (0.25 lux): 60m
• Peak Beam Intensity: 884.5 cd
• Input Voltage: 6-28V DC
• Ingress Protection: IP68
• Housing Material: Aluminum alloy
• Lens Material: Impact-resistant polycarbonate
• Finish: UV-resistant black powder coat
• LED Lifespan: 50,000+ hours
• Quantity: 2 (sold as a pair)
• Weight: 0.6 lbs (kit)
• UPC: 849774014994
• Warranty: Limited Lifetime

Included Components

• 2x Rigid Industries Ignite Flush Mount LED Lights (Black, Diffused)
• 2x Flush Mount Brackets
• 1x Hardware Kit

Product Description

The Rigid Industries 20641 Ignite Backup Kit is a pair of flush-mount LED lights designed to supplement or replace the inadequate factory backup lighting found on most vehicles. Each light measures just 1.4 by 1.4 by 2 inches - Rigid's smallest forward-projecting LED - yet delivers 1,000 raw lumens of diffused flood output per light, providing a wide, even spread of illumination directly behind the vehicle during reversing. At under 1 amp of draw each, they can typically be wired directly into the vehicle's existing backup light circuit without requiring a relay or upgraded wiring.

The flush mount design installs recessed into any flat panel surface using a 1.75-inch hole, making these lights as clean in appearance as they are functional. Built with an IP68-rated polycarbonate lens and UV-resistant powder-coated aluminum housing, the Ignite is equally at home on daily drivers, Jeeps, UTVs, motorcycles, and marine vessels. Built-in over/under voltage, RFI/EMI, and reverse polarity protection guard against electrical damage. Note: wiring harness is not included. Backed by Rigid Industries' Limited Lifetime Warranty.
