Rigid Industries 240603 Radiance Plus SR-Series 40in RGBW LED Light Bar Black

Vehicle Fitment

• Universal - compatible with off-road trucks, SUVs, Jeeps, UTVs, agricultural equipment, marine vessels, and industrial applications
• Off-road use only - not legal for on-road use on public streets or highways
• Compatible with all SR-Series light covers and mounting accessories

Fitment Notes

• Universal surface mount - vehicle-specific or universal mounting bracket required (mounting hardware included)
• Input voltage: 9-15V DC - designed for 12V systems
• RGBW wiring harness and backlight switch sold separately - Rigid Industries part number 40200
• Sold individually (1 light bar)
• Off-road use only

Features

• 8 selectable RGBW backlight colors - Red, Green, Blue, Light Blue, Purple, Amber, White, or Rotating - toggled independently via switch logic (switch sold separately)
• Broad Spot optics - optimized forward-projecting beam for long-distance illumination with wide spread
• Single-row SR-Series construction - same superior build quality and compatibility as Rigid's SR-Series product line
• Black exposed printed circuit board aesthetic with prominent Rigid branding plates for a clean, aggressive look
• 22,848 raw lumens from 28 LEDs in a low-profile single-row form factor
• High-grade aluminum alloy housing and heat sink with UV-resistant black powder-coat finish
• High-impact polycarbonate lens for protection against trail debris
• Pressure equalizing vent prevents moisture ingress during temperature cycling
• IP68 rated - fully dust-tight and submersion-proof
• Over/under voltage protection, RFI/EMI protection, and reverse polarity protection
• RoHS compliant
• Designed, engineered, and assembled in the USA
• Backed by Rigid Industries' 10-Year Warranty

Specifications

• Part Number: 240603
• Series: Radiance Plus SR-Series
• Length: 40 inches
• Beam Pattern: Broad Spot
• Backlight Options: 8 (Red, Green, Blue, Light Blue, Purple, Amber, White, Rotating)
• Housing Color: Black
• LED Count: 28
• Wattage: 197W
• Amp Draw: 14.8A
• Raw Lumens: 22,848 lm
• Lux @ 10m: 2,800.68
• Beam Distance (1 lux): 529.2m
• Beam Distance (0.25 lux): 1,058.45m
• Horizontal Beam Angle: 24°
• Input Voltage: 9-15V DC
• Ingress Protection: IP68
• Housing Material: High-grade aluminum alloy
• Lens Material: High-impact polycarbonate
• Finish: UV-resistant black powder coat
• Row Configuration: Single row
• Weight: 15.0 lbs
• Wiring Harness/Switch: Sold separately (part #40200)
• Quantity: 1 (sold individually)
• Warranty: 10-Year

Included Components

• 1x Rigid Industries Radiance Plus SR-Series 40-inch LED Light Bar (Black, RGBW)
• 2x Mounting Brackets
• 1x Hardware Kit

Product Description

The Rigid Industries 240603 Radiance Plus SR-Series is a 40-inch single-row LED light bar that combines Rigid's proven forward-projecting performance with programmable RGBW backlighting - all in the same low-profile SR-Series form factor. Eight backlight color options (Red, Green, Blue, Light Blue, Purple, Amber, White, and Rotating) are independently controlled via switch logic, giving owners the ability to customize the bar's appearance to match a vehicle's lighting scheme or personal style. The forward-projecting Broad Spot optics deliver 22,848 raw lumens of long-distance illumination, while the exposed black PCB and Rigid branding plates give the bar a distinctly aggressive appearance.

Built with the same SR-Series construction as Rigid's standard performance lineup, the Radiance Plus is fully compatible with all SR-Series light covers and mounts. The aluminum alloy housing, IP68-rated polycarbonate lens, and GORE-style pressure equalizing vent ensure long-term reliability in dust, mud, rain, and water submersion. Over/under voltage, RFI/EMI, and reverse polarity protections guard against electrical damage. Note: the RGBW wiring harness and backlight switch are sold separately as part number 40200. Backed by Rigid Industries' 10-Year Warranty. Off-road use only.
