Rigid Industries 931314 SR-Series Pro 30in Spot/Drive Combo LED Light Bar Black

Vehicle Fitment

• Universal - compatible with off-road vehicles, trucks, UTVs, agricultural equipment, marine vessels, and industrial applications
• Off-road use only - not legal for on-road use on public streets or highways

Fitment Notes

• Universal surface mount - a vehicle-specific mounting bracket or universal mounting hardware is required (not included)
• Designed for 9-36V DC electrical systems - compatible with 12V and 24V vehicles
• Off-road use only; not street legal in most jurisdictions

Features

• Spot/Drive Combo beam pattern - combines Hyperspot (5-degree ultra-narrow concentrated spot) and Driving optics in a single bar for extreme distance coverage and wide horizontal spread simultaneously
• Patented Specter optics system - driving beam creates an oblong output with a bright center hot spot plus strong horizontal dispersion for a wide, usable field of illumination
• Up to 111% more raw lumens than previous SR-Series generation - 21,318 raw lumens from 34 LEDs
• Low-profile single-row design - measures less than 2 inches tall, ideal for space-restricted mounting locations
• Extruded high-grade aluminum alloy housing with UV-resistant black powder-coat finish
• Impact-resistant polycarbonate lens for protection against trail debris
• Integrated thermal management system for sustained performance in demanding conditions
• GORE® pressure equalizing vent prevents moisture ingress during temperature cycles
• Over/under voltage protection, RFI/EMI protection, and reverse polarity protection
• IP68 rated - fully dust-tight and submersion-proof
• SAE J575 compliant for shock and vibration resistance
• 50,000+ hour LED lifespan
• Instant on/off - no warm-up required
• Designed, engineered, and assembled in the USA
• Backed by Rigid Industries' Limited Lifetime Warranty

Specifications

• Part Number: 931314
• Series: SR-Series Pro
• Length: 30 inches
• Beam Pattern: Spot/Drive Combo (Hyperspot + Driving)
• Housing Color: Black
• LED Count: 34
• Wattage: 205W
• Amp Draw: 14.64A
• Raw Lumens: 21,318 lm
• Lux @ 10m: 3,802
• Peak Beam Intensity: 380,181 cd
• Beam Distance (1 lux): 617m
• Beam Distance (0.25 lux): 1,233m
• Horizontal Beam Angle: 27°
• Vertical Beam Angle: 17°
• Input Voltage: 9-36V DC
• Operating Temperature: -40°F to +145°F
• Ingress Protection: IP68
• Housing Material: Extruded aluminum alloy
• Lens Material: Impact-resistant polycarbonate
• Finish: UV-resistant black powder coat
• Row Configuration: Single row
• Profile Height: Less than 2 inches
• Weight: 11.0 lbs
• UPC: 849774031533
• Warranty: Limited Lifetime

Included Components

• 1x Rigid Industries SR-Series Pro 30-inch LED Light Bar (Black)
• 1x Wiring Harness
• 1x Mounting Hardware Kit
• 1x Installation Instructions

Product Description

The Rigid Industries 931314 SR-Series Pro is a 30-inch single-row LED light bar combining Hyperspot and Driving beam optics in one compact, low-profile package. At under 2 inches tall, it fits where full-size dual-row bars cannot, yet delivers 21,318 raw lumens from 34 LEDs - up to 111% more output than the previous SR-Series generation. The Hyperspot optic provides a 5-degree ultra-narrow beam for visibility at extreme distances, while the Driving optic creates a wide oblong output with a strong center hot spot and substantial horizontal spread. Together, the Spot/Drive Combo pattern covers both distance and width simultaneously.

Built from extruded high-grade aluminum alloy with an IP68-rated polycarbonate lens, the SR-Series Pro is engineered for full submersion resistance and trail-level abuse. A GORE pressure equalizing vent prevents moisture from being drawn inside during temperature cycling, while integrated thermal management protects the LEDs for a rated 50,000+ hour lifespan. The 9-36V input range covers both 12V and 24V systems, and built-in over/under voltage, RFI/EMI, and reverse polarity protections guard against electrical damage. Designed, engineered, and assembled in the USA. Backed by Rigid Industries' Limited Lifetime Warranty. Off-road use only.
