Rigid Industries 921314 SR-Series PRO 20" Spot/Drive Combo LED Light Bar

Vehicle Fitment

Universal fit - not vehicle-specific. Compatible with virtually any platform including trucks, Jeeps, SUVs, UTVs, ATVs, powersports, marine vessels, agricultural equipment, and first responder vehicles. Mounting hardware and wiring harness are included. Compatible with SR-Series 10-inch covers and mounts. For off-road use only.

Fitment Notes

• Single-row design measuring under 2 inches tall - suited for bumper openings, lower windshield frames, grille inserts, and any tight-clearance mounting location where a dual-row bar would not fit
• Compatible with Rigid Industries SR-Series 10-inch light covers and mounting hardware
• Replaces legacy part number 921313 - buyers upgrading from the previous generation SR-Series Spot/Drive Combo can use 921314 as a direct PRO-technology replacement
• Available in 9-36V DC - operates on 12V automotive and 24V commercial systems
• For off-road use only - not street legal for on-highway use in the United States

Features

• Spot/Drive Combo optics in a single-row format - combines the long-distance reach of a spot beam with the wider horizontal spread of a driving beam in one 20-inch single-row bar; this is the SR-Series PRO version of the same dual-purpose beam concept found in the E-Series PRO Spot/Flood Combo (120313), adapted for the sub-2-inch low-profile single-row form factor
• 22 LEDs delivering 17,424 raw lumens at 132 watts - the SR-Series PRO Spot/Drive Combo produces more output than a pure spot variant of the same length because the combined optic system activates more LEDs in a coordinated pattern; peak intensity of 305,299 candela with 3,053 lux at 10 meters and a beam distance of 553 meters at 1 lux
• Under 2 inches tall - the SR-Series PRO form factor is designed for installations where a dual-row E-Series bar is too tall; the single-row construction maintains meaningful output while fitting in lower-profile mounting locations that dual-row bars cannot
• Up to 111% more raw lumens than the original SR-Series - PRO LED technology delivers substantially improved output over the legacy 921313 this product replaces, while maintaining the same compact single-row profile
• Extruded aluminum housing with UV-resistant black powder coat - custom oversized heat sink keeps 22 LEDs operating within optimal thermal range for consistent, sustained output
• Blacked-out circuit board with updated Rigid branding - refined appearance in both mounted and unmounted configurations
• IP68 certified - fully sealed against dust and water submersion; suitable for all weather conditions and water crossings
• SAE J575 compliant for shock and vibration - tested for sustained off-road, motorsport, and commercial use vibration loads
• GORE Pressure Equalizing Vent prevents moisture migration through thermal pressure cycling
• Impact-resistant polycarbonate lens - abrasion and shatter-resistant for exposed mounting locations
• Over/under voltage protection and RFI/EMI filtering - full electrical protection
• 50,000+ hour LED lifespan; instant on/off with no warm-up
• Operating temperature: -40°F to 145°F
• RoHS compliant
• Designed, engineered, and assembled in the USA (Gilbert, AZ)

Specifications

• Part Number: 921314
• Series: SR-Series PRO
• Light Type: Single Row LED Light Bar (straight)
• Beam Pattern: Spot/Drive Combo
• Size: 20"
• LED Count: 22
• Raw Lumens: 17,424
• Watts: 132W
• Current Draw @ 14V: 9.43A
• Voltage Range: 9-36V DC
• Lux @ 10m: 3,053
• Peak Beam Intensity: 305,299 cd
• Beam Distance @ 1 LUX: 553m
• Beam Distance @ 0.25 LUX: 892m
• Horizontal Beam Angle: 19°
• Vertical Beam Angle: 17°
• Height: Under 2"
• Weight: 4.12 lbs
• Housing: Extruded Aluminum Alloy, UV-Resistant Black Powder Coat
• Lens: Impact-Resistant Polycarbonate, Clear
• Mount Type: Surface Mount
• Cover/Mount Compatibility: SR-Series 10-inch covers and mounts
• IP Rating: IP68
• Operating Temperature: -40°F to 145°F
• LED Lifespan: 50,000+ hours
• Compliance: IP68, SAE J575 (Vibration), RoHS, RFI/EMI, Over/Under Voltage, GORE Pressure Equalizing Vent
• Country of Origin: USA (Gilbert, AZ)
• Supersedes: 921313
• Warranty: Rigid Industries Limited Lifetime Warranty

Included Components

• 1x Rigid Industries SR-Series PRO 20" Spot/Drive Combo LED Light Bar (921314)
• 1x Wiring Harness with Switch
• 1x Pair of Mounting Brackets with hardware

Product Description

The Rigid Industries 921314 is the SR-Series PRO 20-inch Spot/Drive Combo LED light bar - a 20-inch single-row bar in the low-profile SR-Series format combining spot and driving optics for a balanced long-range and wide-coverage beam from a single compact housing. The 921314 replaces the previous-generation 921313 with PRO-technology LEDs that deliver up to 111% more raw lumens from the same physical footprint: 17,424 lumens at 132 watts from 22 LEDs, measuring under 2 inches tall across its full 20-inch length.

The Spot/Drive Combo is the SR-Series PRO's equivalent of the dual-purpose beam concept: rather than choosing between a narrow long-range spot and a moderate-width driving beam, the 921314 combines both optic types in a single bar. The result is 3,053 lux at 10 meters, 553 meters at 1 lux, and a peak intensity of 305,299 candela - delivering meaningful forward distance reach while maintaining the wider horizontal coverage of a driving pattern. This combination is more versatile across mixed-speed and mixed-terrain use than a pure spot, without sacrificing the forward reach that makes the SR-Series PRO a meaningful upgrade over standard flood or diffused pods.

The sub-2-inch height is the SR-Series PRO's signature capability. Where the E-Series PRO 20-inch Spot/Drive Combo (dual-row, 3.25" tall) cannot fit, the 921314 can - making it the appropriate choice for lower bumper slots, windshield frame pockets, grille inserts, and narrow mounting openings on modern trucks and SUVs that were designed with tight tolerances. IP68 sealing, SAE J575 vibration certification, a GORE Pressure Equalizing Vent, and full electrical protection bring the complete Rigid durability package to the compact single-row form factor. SR-Series 10-inch covers and mounts are compatible. Designed, engineered, and assembled in the USA. Limited Lifetime Warranty.
