Ridetech 12293210 Front Touring HQ Coil-Over Each for 2015-2026 Ford F-150

Vehicle Fitment

• 2015-2026 Ford F-150 (2WD and 4WD, including BlueCruise and PowerBoost-equipped trucks)

Fitment Notes

• Sold individually (each) - a complete front installation requires two units
• Not compatible with F-150 Lightning or Raptor models
• Setting ride height below 4" requires Ridetech tubular upper arms and slotting the frame in the lower control arm mounts
• Trucks with headlight-mounted height sensors (driver side only) require bracket kit #12299501; trucks with four sensors (onboard scale option) require bracket kit #12299502

Features

• Lowers 1.5"-4.5" in front
• Fox Factory Performance 2.0 monotube aluminum body coil-over with large IFP piston
• Rubber-isolated design mitigates felt NVH inside the cabin
• 24-position rebound adjustment for tunable suspension response
• 11% lighter than OE factory Ford front strut suspension, reducing unsprung weight
• OE-style loaded coil-over strut ships pre-assembled and ready to install
• 100% bolt-on - no welding or fabrication required
• 1,000,001-mile warranty
• Made in the USA

Specifications

• Location: Front
• Ride height drop: 1.5"-4.5"
• Rebound adjustment: 24 positions
• Design: Monotube, aluminum body, rubber-isolated

Included Components

• 1x Front Touring HQ Coil-Over Shock
• 1x Coil Spring
• Spring Mounts

Product Description

The Ridetech 12293210 is the individual front coil-over strut used in Ridetech's Touring Lowering Kit for 2015-2026 F-150s. Built around a Fox Factory Performance 2.0 monotube body with a large IFP piston, it drops the front 1.5"-4.5" while the rubber-isolated design keeps NVH in check for daily-driver comfort - unlike Ridetech's StreetGRIP variant, which uses hard-mounted bearings for maximum responsiveness.

It ships pre-assembled and ready to install, with 24 positions of rebound adjustment for fine-tuning ride feel. This is the single-unit part number, useful for replacing one strut or building a kit a la carte - a full front installation needs two.
