Radium 20-1827-12 Compact Fuel Vent Charcoal Canister, 3/4in Hose, Universal

Compatibility

• Universal - fits any EFI or carbureted fuel system's vent line
• Designed to pair with Radium's Fuel Cell Vent Kit (20-0484-12) for seamless integration with a Radium fuel cell surge tank, but works as a standalone vent-line filter on any vehicle running 3/4 in. vent hose

Fitment Notes

• Compact-size canister - holds less activated carbon than Radium's standard-size canister (20-1828-12), so may need more frequent servicing, but has a smaller footprint for tight mounting locations
• Designed for 3/4 in. fuel vent hose (high flow); a 1/2 in. hose version (20-1827-08) and a fitting-only 16AN ORB version (20-1827-00) are sold separately for other hose sizes
• Recharge/service kit (20-1827-SK) sold separately

Features

• CNC-machined from 6061 aluminum, Type-II anodized for corrosion resistance
• Preassembled, vibratory-packed activated carbon inside a 150-micron strainer and anodized aluminum baffle - prevents loose carbon debris from escaping
• 16AN ORB (1-5/16"-12) female ports, usable interchangeably as inlet or outlet
• Two 4AN ORB (7/16"-20) female drain ports at the bottom with preinstalled plugs; compatible with optional Petcock Drain Kit
• 3/4 in. barb fitting allows direct air filter attachment
• Tested to reduce fuel vapor at the vent outlet from over 10,000 ppm unfiltered to under 50 ppm
• Suitable for both EFI and carbureted fuel systems

Specifications

• Size: Compact
• Hose Size: 3/4 in.
• Material: 6061 aluminum, Type-II anodized
• Ports: 16AN ORB (inlet/outlet, interchangeable); 2x 4AN ORB drain ports (plugged)
• Carbon Media: Activated carbon, vibratory-packed, 150-micron strainer

Included Components

• 1x Compact Fuel Vent Charcoal Canister (preassembled with activated carbon)
• Preinstalled drain port plugs

Product Description

The Radium 20-1827-12 is a compact fuel vent charcoal canister that filters odor and fuel vapor out of the tank vent line before it reaches atmosphere, built for setups using 3/4 in. vent hose. Testing at the vent outlet showed unfiltered fuel vapor maxing out a gas detector at over 10,000 ppm, while the canister brought that down to an undetectable level under 50 ppm - a meaningful difference for anyone dealing with fuel smell around a fuel cell or aftermarket tank.

Machined from anodized 6061 aluminum with a preassembled, vibratory-packed carbon core, it's built to hold up under vibration without shedding media into the vent line. Being the compact version, it trades some carbon capacity (and therefore service interval) for a smaller footprint - worth keeping in mind if you'd rather service less often, in which case Radium's standard-size canister holds roughly 5x more carbon.
