ORACLE 5895-339-8 ColorSHIFT RGB+W 8-Pod Underbody Rock Light Kit IP68 22LED

Vehicle Fitment

• Universal Fitment - Compatible with virtually any 4x4, off-road vehicle, Jeep, truck, SUV, or car equipped with a 9V-32V electrical system and a suitable mounting surface for the pods

Fitment Notes

• This is a universal rock light kit - no vehicle-specific wiring adapter or bracket is included; mounting locations and wire routing will vary by vehicle
• Requires connection to the vehicle's battery using the included ring terminal leads and inline fuse - no plug-and-play OEM connector is used
• Compatible with 9V-32V electrical systems - suitable for standard 12V automotive and 24V systems
• Estimated installation time is approximately 4 hours depending on the vehicle and desired pod placement
• Not DOT approved - not intended or street legal for on-road use; designed for off-road and aesthetic underbody/wheel well lighting only
• Bluetooth control requires a smartphone running iOS 7 or later, or Android 4.3 or later, with the ORACLE smartphone app installed
• Includes 8 pods - sufficient for one pod per wheel well on a standard 4-wheel vehicle with remaining pods available for additional underbody placement

Features

• 230° extra-wide beam angle - ORACLE's oversized pod design uses 3 separate LED emitters per pod to deliver the widest coverage of any rock light on the market, eliminating the need for multiple pods per wheel well to achieve complete illumination
• 22 LEDs per pod arranged in 3 emitters - maximizes brightness and angular coverage simultaneously for full wheel well saturation in a single pod
• True 6,000K white mode - the RGBW 5050 chip delivers a dedicated, full-output pure white LED in addition to the RGB color spectrum, producing a genuine daylight-white color instead of a mixed-color approximation
• ORACLE ColorSHIFT® technology - select from thousands of colors via the RGB+W color mixing system, with full brightness control, color transitions, strobing patterns, and music/sound-reactive modes
• "Dual-Control" system - each kit is controlled by both a free Bluetooth smartphone app (iOS 7+ / Android 4.3+) AND an included wireless RF remote, giving the user multiple control options simultaneously
• Music and sound reactive lighting mode - the system responds in real time to audio input for dynamic, beat-synced color shows
• IP68 waterproof-rated connectors and housing - built to withstand full submersion, mud, trail water crossings, and pressure washing
• Aluminum housing with black powdercoat finish - provides superior heat dissipation compared to plastic-bodied alternatives, along with a durable, corrosion-resistant exterior finish
• Plug-and-play pod-to-control-box connection - each pod connects directly to the central control box with waterproof IP68 connectors for simplified installation and easy pod replacement if needed
• Pre-wired on/off switch - allows manual system shutoff without accessing the app or remote
• Battery connection leads with ring terminals and inline fuse - simplifies direct battery installation with proper circuit protection included
• 18 AWG wiring throughout - appropriate gauge for the current draw of this system at full load

Specifications

• Part Number: 5895-339-8
• Product Line: ColorSHIFT® RGB+W Underbody Wheel Well Rock Light Kit
• LED Chip: 5050 RGBW
• LEDs per Pod: 22 (in 3 emitters)
• Number of Pods: 8
• Input Voltage: 9V-32V DC
• Wattage: 7W per pod / 28W total
• Total Lumens (White Mode): 2,000 LM+
• White Color Temperature: 6,000K
• Beam Angle: 230° (extra wide)
• Amp Draw @ 12VDC: Red 0.56A / Green 0.65A / Blue 0.56A / White 0.63A per pod
• Housing Material: Aluminum
• Finish: Black powdercoat
• Ingress Protection: IP68
• Wire Gauge: 18 AWG
• Control: Bluetooth smartphone app (iOS 7+ / Android 4.3+) + included wireless RF remote
• DOT Approved: No - for off-road / aesthetic use only
• Warranty: 1-year limited
• Quantity: 8-pod complete kit

Included Components

• 8x ORACLE ColorSHIFT RGB+W LED Rock Light Pods (22 LEDs / 3 emitters each)
• 1x Central control module / Bluetooth controller
• 1x Wireless RF remote control
• 1x Pre-wired on/off switch
• 1x Battery connection harness with ring terminals and inline fuse
• 1x Mounting hardware set
• Waterproof IP68 pod-to-controller wiring and connectors

Product Description

The ORACLE Lighting 5895-339-8 is an 8-pod ColorSHIFT® RGB+W underbody and wheel well rock light kit designed to deliver full-coverage illumination beneath any 4x4, Jeep, truck, or SUV. The standout engineering feature of this kit is the oversized pod design - each of the 8 pods houses 22 LEDs arranged across 3 separate emitters positioned to project light across a massive 230° angle. Where conventional rock lights typically require multiple pods per wheel well to achieve complete illumination, ORACLE's extra-wide beam design allows a single pod to cover an entire wheel well with no dark spots. The 3-emitter layout directs light in three distinct angular directions simultaneously, saturating the surrounding area with consistent output regardless of where the pod is mounted.

The 5050 RGBW LED chip at the heart of each pod includes a dedicated white LED channel separate from the RGB color mixing elements. This means the 6,000K white output is a true, full-power daylight white - not a mixed RGB approximation - delivering 2,000+ total lumens of crisp, clean white illumination across the full 8-pod array. For color modes, ORACLE's ColorSHIFT® technology provides access to thousands of color combinations through the RGB channels, with full control over brightness, color transitions, strobe patterns, and a music-reactive sound mode that pulses the lights in real time with audio. The "Dual-Control" system provides two simultaneous control paths: a free Bluetooth smartphone app compatible with iOS 7+ and Android 4.3+, and an included wireless RF remote - giving the driver flexibility to switch between control methods at will.

The aluminum housing and black powdercoat finish give each pod a clean, aggressive appearance while also providing significantly better heat management than plastic-bodied alternatives. IP68 waterproof rating across the pods, connectors, and wiring ensures the kit holds up to full trail immersion, mud, high-pressure washing, and extended exposure to the elements. Installation uses a centralized control box with waterproof plug-and-play pod connectors - each pod snaps into the box individually, allowing the harness to be routed cleanly around the chassis without splicing. Battery connection is made through the included ring terminal leads with an inline fuse for circuit protection. A pre-wired on/off switch provides a simple manual override for the entire system. The kit carries a 1-year limited warranty from ORACLE Lighting.
