OMIX 16536.07 AMC 20 1-Piece Axle Conversion Bearing & Hardware Kit 76-86 Jeep

Vehicle Fitment

• 1976-1982 Jeep CJ-5 (with AMC Model 20 Rear Axle & 1-Piece Conversion Axles)
• 1976-1986 Jeep CJ-7 (with AMC Model 20 Rear Axle & 1-Piece Conversion Axles)
• 1981-1986 Jeep CJ-8 Scrambler (with AMC Model 20 Rear Axle & 1-Piece Conversion Axles)

Fitment Notes

• Fits AMC Model 20 rear differentials equipped with 1-piece conversion axle shafts only - does not fit original 2-piece "C-clip" style axle configurations
• One kit services one side (left or right) - two kits required for complete vehicle rear axle bearing service
• Replaces OE reference: 1-PIECE-K/2
• Not compatible with Dana 44 rear axle applications - see OMIX 16536.05 for Dana 44 CJ fitment

Features

• Complete conversion bearing and hardware kit engineered specifically for AMC 20 rear axles upgraded to 1-piece axle shafts
• Includes all sealing and retention components needed to correctly install a 1-piece axle in the AMC 20 housing without sourcing additional hardware
• 5 replacement wheel studs included for restoring wheel mounting integrity during the bearing service
• RTV sealant included for proper axle flange sealing during reassembly
• OE-spec replacement components meet or exceed original AMC 20 axle specifications for reliable on-road and off-road performance
• Backed by OMIX's Limited 5-Year Manufacturer's Warranty

Specifications

• Part Number: 16536.07
• Axle Type: AMC Model 20 Rear, 1-Piece Conversion
• Position: Left or Right (one side per kit)
• Axle Seals Included: Yes (Inner & Outer)
• OE Reference: 1-PIECE-K/2
• Warranty: Limited 5-Year
• UPC: 804314124045
• Sold: As a Kit (One Side)

Included Components

• 1x Axle Shaft Bearing
• 1x Inner Axle Seal
• 1x Outer Axle Seal
• 1x Bearing Retainer
• 1x Spacer
• 5x Wheel Studs
• 1x RTV Sealant

Product Description

The OMIX 16536.07 is a complete rear axle conversion bearing and hardware kit for 1976-1986 Jeep CJ-5, CJ-7, and CJ-8 Scrambler models equipped with the AMC Model 20 rear differential that have been converted to 1-piece axle shafts. The original AMC 20 axle used a 2-piece "C-clip" style axle design that is prone to catastrophic axle shaft retention failure - a well-known weakness of this axle. Many CJ owners address this by converting to full-floating 1-piece axle shafts, which require different bearing, seal, and retainer hardware than the factory setup.

This kit includes everything needed to service one side of the axle after a 1-piece conversion: the axle bearing, inner and outer seals, bearing retainer, spacer, five replacement wheel studs, and RTV sealant for proper flange sealing during reassembly. Two kits are required to service both sides of the rear axle. This kit is specific to the AMC 20 axle with 1-piece conversion shafts - it does not apply to Dana 44 rear axle applications. Backed by OMIX's Limited 5-Year Manufacturer's Warranty.
