Konig HP97510406 Hyperspec 17x9 5x100 +40mm Anthracite Machined Lip Wheel

Vehicle Fitment

• Universal - 5x100mm bolt pattern, 73.1mm hub bore
• Compatible with many 5x100 vehicles including Subaru BRZ, WRX (2001-2014), Impreza, Toyota GR86, Scion FR-S, Volkswagen Golf/GTI (Mk4-Mk7), Jetta, and more

Fitment Notes

• This is a universal 5x100mm wheel - verify bolt pattern, offset, hub bore, and caliper clearance for your specific vehicle before purchase
• Hub-centric rings may be required for vehicles with a hub bore smaller than 73.1mm
• 17x9 with +40mm offset provides an aggressive width with a moderate tuck - confirm fender clearance on your specific vehicle and suspension setup
• Lug nuts are not included - confirm your vehicle's lug nut seat style before purchase
• Verify brake caliper clearance - curved spoke design is engineered for maximum BBK compatibility

Features

• Flow Formed construction compresses aluminum molecules for a lighter, stronger wheel with greater shock resistance than traditional cast designs
• Classic 5-spoke tapered design with a pronounced stepped lip for a simple, aggressive aesthetic
• Anthracite Metallic finish with mirror machined lip for a refined two-tone contrast
• Curved spokes engineered for maximum brake caliper clearance
• Knurled bead seats prevent tire slippage during high-torque and high-performance driving
• C-channel rear flange for increased barrel strength and rigidity
• Engineered using Finite Element Analysis (FEA) for optimized weight, strength, and stress distribution
• Snap-in center cap with Konig logo included
• 15-25% lighter than traditional cast wheels of comparable size
• Popular fitment for autocross, track day, and time attack builds on BRZ/GR86 and Subaru platforms

Specifications

• Wheel Diameter: 17 inches
• Wheel Width: 9 inches
• Bolt Pattern: 5x100mm
• Offset: +40mm
• Backspacing: 6.58 inches
• Hub Bore: 73.1mm
• Load Rating: 1,542 lbs
• Spoke Count: 5
• Construction: Flow Formed, One-Piece
• Finish: Anthracite Metallic with Mirror Machined Lip
• Knurled Bead Seats: Yes
• Exposed Lugs: Yes
• True Directional: No

Included Components

• 1x Konig Hyperspec Wheel (HP97510406)
• 1x Snap-In Center Cap

Product Description

The Konig Hyperspec is the brand's newest 5-spoke Flow Formed wheel, engineered to deliver lightweight performance with a clean, motorsport-inspired design. Its tapered spoke design and pronounced stepped lip create a simple yet bold aesthetic, while the Anthracite Metallic finish with a mirror machined lip delivers a sophisticated two-tone appearance that works across a wide range of vehicle colors and build styles. The 17x9 configuration provides an aggressive width in a compact 17-inch diameter - ideal for enthusiasts who prioritize tire sidewall, mechanical grip, and unsprung weight reduction over visual diameter.

Built with Flow Formed construction, the Hyperspec compresses the aluminum barrel under heat and pressure to produce a wheel that is 15-25% lighter and significantly stronger than a comparable cast design. Curved spokes are specifically shaped to maximize clearance for both factory and aftermarket big brake kits, making the Hyperspec compatible with popular upgrades from Brembo, Wilwood, StopTech, and AP Racing. Knurled bead seats machined into the barrel prevent tire slippage under aggressive cornering, braking, and acceleration loads, while a c-channel rear flange reinforces the barrel for additional structural rigidity.

The 5x100mm bolt pattern with a 73.1mm hub bore covers one of the most popular fitment ranges for sport compact and track-oriented builds, including the Subaru BRZ and Toyota GR86, older Subaru WRX and Impreza models, Scion FR-S, and Volkswagen Golf/GTI (Mk4-Mk7). The +40mm offset provides a balanced stance that works well on both stock and lowered suspension setups without requiring excessive fender modification. The wheel is sold individually and includes a snap-in center cap. The Hyperspec is also available in Matte Bronze and spans sizes from 15 to 19 inches across multiple bolt patterns, making it one of the most versatile additions to Konig's Flow Formed lineup.
