King Shocks 25AB414-103 Bump Stop Mounting Sleeve 2.5in 4in Stroke

Vehicle Fitment

• Universal - weld-on fabrication component for custom chassis and suspension builds

Fitment Notes

• Fits King 2.5in diameter bump stops with a 4in stroke; compatible with Fox Racing bump stop canisters of the same threaded-top style
• Note: King's 2nd generation hydraulic bump stops use a billet aluminum top with 1-1/8in thread (older 1st generation used 7/8in thread) - confirm which generation your bump stop uses before installing

Features

• Manufactured from top-quality .093 chromoly (4130) tubing for strength and durability
• Machined for clearance at the top end before laser-cut tops are TIG-welded on
• Snug-fit design at the open end holds the bump stop around its entire outside diameter
• Locating pin registers into the top plate; bump stop's threaded boss bolts securely to the mount
• Avoids the crushing effect of pinch-bolt style bump stop mounts
• Delivered raw for direct weld-on installation to your chassis

Specifications

• Material: Chromoly (4130), .093 wall tubing
• Bump stop diameter: 2.5in
• Stroke length: 4in
• Installation: Weld-in, raw finish
• Quantity: Sold individually

Included Components

• 1x Bump stop mounting sleeve

Product Description

The King Shocks 25AB414-103 is a chromoly bump stop mounting sleeve built for King's 2.5in diameter bump stops with a 4in stroke, machined from top-quality .093 wall tubing with laser-cut, TIG-welded tops. The sleeve's snug-fit design secures the bump stop around its entire outside diameter, avoiding the pinch and potential damage caused by traditional pinch-bolt mounting styles.

A locating pin registers into the top plate while the bump stop's threaded boss bolts directly into the mount for a secure, rattle-free connection. Delivered raw, this sleeve is intended to be welded directly onto a custom chassis or fabricated suspension setup, giving builders a durable, race-proven mounting solution for their bump stop system.
