JE Pistons 359152 Forged Pistons for 2013-2021 Subaru BRZ FA20 2.0L 12.5:1 CR

Vehicle Fitment

• 2013-2021 Subaru BRZ (FA20, 2.0L H4, RWD)
• 2013-2021 Scion FR-S (FA20, 2.0L H4, RWD)
• 2017-2021 Toyota 86 (FA20, 2.0L H4, RWD)

Features

• Designed for high-performance and forced induction applications
• Utilizes JE's proprietary Aligned Grain Flow forging technology
• Features thermal barrier crown coating to reflect heat into the combustion chamber
• Equipped with skirt coating to reduce friction and wear
• Includes lateral gas ports to maintain ring seal at high RPM and boost levels
• Comes with thick-wall wrist pins manufactured by Trend Performance
• Made from 2618 T6 high-tensile forged aluminum for superior strength and durability
• 100% made in the USA

Specifications

• Bore Diameter: 86.00 mm (3.386 inches)
• Compression Height: 1.290 inches (32.75 mm)
• Piston Volume: -1.00 cc
• Compression Ratio: 12.5:1
• Piston Material: 2618 T6 high-tensile forged aluminum
• Forging Type: Round
• Wrist Pin Diameter: 22 mm (0.866 inches)
• Wrist Pin Length: 2.250 inches
• Ring Set Included: Yes (1.0 x 1.2 x 2.8 mm)
• Pin Locks Included: Yes

Included Components

• 4x JE forged pistons
• 4x wrist pins (22 mm diameter)
• 4x pin locks
• 1x JE ring set (1.0 x 1.2 x 2.8 mm)

Product Description

The JE Pistons 359152 Forged Piston Kit is engineered for Subaru's FA20 2.0L H4 engine, commonly found in the 2013-2021 Subaru BRZ, Scion FR-S, and Toyota 86. This kit is ideal for enthusiasts seeking to enhance their engine's performance, especially in high-boost applications. The pistons are crafted from 2618 T6 high-tensile forged aluminum and feature JE's proprietary Aligned Grain Flow forging technology, ensuring exceptional strength and durability.

Designed with performance in mind, the pistons come with a thermal barrier crown coating to reflect heat back into the combustion chamber, improving exhaust gas scavenging. The skirt coating reduces friction and wear, while the lateral gas ports help maintain ring seal at high RPM and boost levels. The kit includes wrist pins, pin locks, and a premium ring set, providing everything needed for a complete piston upgrade.

Whether you're rebuilding your engine or upgrading for increased performance, the JE Pistons 359152 Forged Piston Kit offers the reliability and strength required for high-performance builds.
