ICON K53132B Stage 2 Suspension Billet UCA 0-3in for 96-02 4Runner

Vehicle Fitment

• 1996-2002 Toyota 4Runner

Fitment Notes

• Coilover heights indicated are for a stock-equipped vehicle
• Bump stop spacer kit available if more threads showing beyond max recommendation are needed
• Recommended max tire size: 33" x 11.25" (larger tires may fit but fender trimming and modifications will be required)

Features

• ICON engineers assessed the 3rd Gen 4Runner front to back to extract maximum performance from every component
• Increased wheel travel and ride quality over stock
• CNC machined 6061 aircraft-grade aluminum components
• Billet aluminum upper control arms add strength, durability, and on-vehicle caster/camber adjustment
• Bolt-on design makes for a straightforward install
• Decreased body roll for improved handling
• Vehicle-specific tuned front and rear shocks provide superior damping and control
• Coilovers are adjustable from 0-3" of lift height
• ICON engineered rear coils provide 1" of lift and improved performance
• Shocks are fully rebuildable and revalveable
• UCAs feature ICON's patented Delta Joint, backed by a 5-year limited warranty when used in a complete ICON suspension system

Specifications

• Series: Stage 2
• Front lift height: 0-3"
• Control arm type: Billet aluminum with Delta Joint
• Coilover type: Extended travel, internal reservoir

Included Components

• 1x Extended travel 2.5 VS IR front coilover kit (58615)
• 1x Billet UCA Delta Joint kit (58500DJ)
• 1x Rear coil spring kit, 1" lift (53015)
• 2x Rear 2.0 VS shocks (56514)

Product Description

The ICON Stage 2 Suspension System (part K53132B) unlocks new levels of performance for your 1996-2002 Toyota 4Runner. Toyota's reputation for reliability continues to draw both hardcore off-road enthusiasts and newcomers to the 3rd Gen platform, and ICON engineers have assessed the 4Runner front to back to develop components that work together to extract maximum performance.

This system includes extended travel 2.5" front coilovers with internal reservoir for increased wheel travel and superior damping, along with a bolt-on design for a straightforward install. CNC machined 6061 aircraft-grade aluminum components and vehicle-specific tuned front and rear shocks provide decreased body roll and improved control.

Billet aluminum upper control arms add strength, durability, and on-vehicle caster/camber adjustment, featuring ICON's patented Delta Joint - a heavy-duty, high angle ball joint combining ball joint durability with uniball performance. ICON engineered rear coils provide 1" of additional lift, and every shock in this system is fully rebuildable and revalveable.
