ICON K53014 Stage 4 Suspension Lift Kit w/UCA 0-3" Lift for 95-04 Toyota Tacoma

Vehicle Fitment

• 1995.5-2004 Toyota Tacoma (2WD/4WD) -- PreRunner and standard cab/Extended cab

Fitment Notes

• Lift kit: 0-3" of front lift; rear lift supported where noted.
• Includes tubular upper control arms (UCAs) for improved articulation.
• Not designed for Tacoma models outside the 1995.5-2004 range (e.g., 2005+ models use different geometry).
• May require alignment and optional extra parts if tracks/wheels are not stock spec.

Features

• 2.5" remote-reservoir coilover front shocks tuned for off-road and street performance.
• Tunable front coilovers with height adjustment for 0-3" lift range.
• Tubular steel upper control arms with high-angle Delta Joint for added travel and durability.
• 2.0 Aluminum Series remote reservoir rear shocks matched to front performance.
• Vehicle-specific tuning for wheel travel and ride quality.\li>
• 6061 aircraft-grade CNC machined components and corrosion-resistant finishes.
• 100 % bolt-on installation -- no drilling or cutting required for listed fitment.
• Maintains factory towing capacity while improving control and articulation.

Specifications

• Front lift range: 0-3" (approx.)
• Shock Size (Front): 2.5" body with remote reservoir
• Shock Size (Rear): 2.0" aluminum remote reservoir design
• Upper Control Arms: Tubular steel with Delta Joint
• Applicability: 1995.5-2004 Toyota Tacoma (all cabins, trims, 2WD/4WD)
• Finish: CAD-plated/coated components for corrosion resistance
• Warranty: Lifetime structural on non-wearable parts; 12 months on shocks

Included Components

• 1x Front left 2.5" remote-reservoir coilover assembly
• 1x Front right 2.5" remote-reservoir coilover assembly
• 1x Pair of tubular upper control arms (left and right)
• 1x Set of rear 2.0" remote-reservoir shocks (left and right)
• Hardware kit including brackets, bushings, springs, instructions

Product Description

The ICON K53014 Stage 4 Suspension System is a premium 0-3" lift kit engineered for the 1995.5-2004 Toyota Tacoma platform. It combines high-performance remote-reservoir coilover front shocks, matched remote-reservoir rear dampers, and heavy-duty tubular upper control arms with ICON's Delta Joint technology--yielding improved wheel travel, better articulation, and refined ride quality both on- and off-road.

Installation is plug-and-play for the listed model years, using factory mounting points and no cutting or drilling. Whether you're upgrading for daily driving or serious off-road use, this system provides a top-tier suspension solution with strong engineering, lifetime structural warranty, and ride control tuned to your vehicle's chassis. Confirm your model year and drivetrain before ordering to ensure fitment.
