ICON K53014B 0-3" Lift Stage 4 System Billet UCA for 1995.5-2004 Toyota Tacoma

Vehicle Fitment

• 1995.5-2004 Toyota Tacoma (4WD, All Cabs) - 0-3" front lift range
• 1995.5-2004 Toyota Tacoma PreRunner (2WD, All Cabs) - 0-3" front lift range

Fitment Notes

• Does NOT fit 2WD Tacoma with 5 wheel lug studs
• Extended travel coilovers REQUIRE aftermarket upper control arms - this kit includes ICON billet aluminum Delta Joint UCAs which satisfy that requirement
• A differential drop kit is recommended for 4WD models at 1.5" of front lift or more to protect CV axle angles and extend drivetrain life
• Front lift range of 0-3" is height-adjustable via the threaded coilover body - lift heights based on a stock-equipped vehicle
• Rear Add-A-Leaf installs in place of factory overload leaves - reduces rear spring rate approximately 10% for improved compliance and provides 1.5" of rear lift over stock
• Recommended aftermarket tires: 33" x 11.50" - larger tires may fit with fender trimming
• Recommended aftermarket wheels: ICON Alloys 17x8.5" w/ 4.75" backspace / 0mm offset; 18x9" or 20x9" w/ 5" backspace / 0mm offset
• 700 lb/in Expedition Coil available separately for heavier-equipped vehicles
• Bump stop spacer kit (ICON #51045) available separately to increase threads showing beyond max recommendation
• For CDCV compression damping adjustment, upgrade to ICON Stage 5 kit K53015B
• Shocks are fully serviceable and rebuildable

Features

• Extended travel 2.5 Series front coilovers with remote reservoir deliver maximum available front wheel travel for the 1st Gen Tacoma platform - superior damping ability and heat dissipation over internal reservoir options
• Billet aluminum Delta Joint UCAs (CNC machined 6061 aluminum, matte anodized) provide on-vehicle caster and camber adjustment for precise alignment tuning - a significant advantage over the tubular steel UCAs in the standard K53014
• ICON patented Delta Joint (U.S. Pat. 10,731,700) combines ball joint durability with uniball-like articulation - greaseable, sealed design resists contamination and operates noise-free
• Height-adjustable threaded coilover body provides 0-3" of front lift height adjustability without disassembly
• ICON-engineered coil springs deliver superior vehicle feel through the full range of suspension travel
• ICON 2.0 Aluminum Series remote reservoir rear shocks provide vehicle-specific valving to balance front-to-rear suspension performance
• Rear Add-A-Leaf Kit replaces OE overload leaf spring - reduces spring rate ~10% for improved small-bump compliance and 1.5" of rear lift
• CAD-plated coilover shock body with 7/8" shaft; FK rod end bearings for extended longevity and minimal deflection
• 100% bolt-on system - no drilling, cutting, or welding required

Specifications

• Front Lift Range: 0-3" (height-adjustable threaded coilover body)
• Rear Lift: 1.5" (from Add-A-Leaf) - stock-equipped vehicle
• Front Coilover: ICON 58715 - Extended Travel 2.5 VS Remote Reservoir (Fixed Valving)
• Front Coilover Body Diameter: 2.5"
• Front Coilover Shaft: 7/8" CAD-Plated
• Front Coilover Lower Mount: FK Rod End Bearing
• Upper Control Arms: ICON 58500DJ - Billet 6061 Aluminum, Matte Anodized, Delta Joint
• UCA Adjustment: On-Vehicle Caster and Camber Adjustment via Machined Adjuster Sleeves
• Rear Shocks: ICON 56502R - 2.0 Aluminum Series Remote Reservoir (0-1.5" rear lift)
• Rear Shock Shaft: 5/8"
• Rear Spring: ICON 51100 - Add-A-Leaf Kit (1.5" rear lift, ~10% spring rate reduction)
• Recommended Aftermarket Tires: 33" x 11.50"
• Country of Origin: United States

Included Components

• 1x ICON 58715 - Extended Travel 2.5 VS Remote Reservoir Front Coilover Kit (pair)
• 1x ICON 58500DJ - Billet Aluminum Delta Joint UCA Kit
• 2x ICON 56502R - 2.0 Aluminum Series Remote Reservoir Rear Shocks
• 1x ICON 51100 - Add-A-Leaf Kit
• All required mounting hardware

Product Description

The ICON K53014B is a complete Stage 4 suspension system for the 1995.5-2004 Toyota Tacoma (4WD and PreRunner), featuring ICON's billet aluminum Delta Joint upper control arms - the key upgrade that distinguishes it from the standard tubular K53014. Constructed from CNC machined 6061 aluminum with a matte anodized finish, the billet UCAs add on-vehicle caster and camber adjustment capability via machined adjuster sleeves, allowing precise alignment tuning at the taller lift heights this system enables. Each UCA features ICON's patented Delta Joint (U.S. Pat. 10,731,700) - a sealed, greaseable ball joint that delivers uniball-like articulation angles with the long-term durability and weather resistance of a traditional ball joint.

At the heart of the system are ICON's 58715 extended travel 2.5 Series remote reservoir front coilovers, which unlock maximum available front wheel travel on this platform when paired with the billet UCAs. The remote reservoir dramatically increases oil volume and heat dissipation for sustained damping performance during hard off-road use. At the rear, two ICON 56502R 2.0 Series remote reservoir shocks provide vehicle-specific valving for balanced front-to-rear performance, while the included Add-A-Leaf kit replaces the factory overload leaves to reduce rear spring rate by approximately 10% - improving small-bump compliance and delivering 1.5" of rear lift. Note: does not fit 2WD Tacomas with 5 lug studs. For CDCV front coilover compression damping adjustment, upgrade to Stage 5 kit K53015B.
