ICON 56523 V.S. 2.0 Aluminum Series Rear Shock Absorber 0-3" for 25-26 4Runner

Vehicle Fitment

• 2025-2026 Toyota 4Runner (All Trims, 2WD/4WD, All Gas Engines)

Fitment Notes

• Shocks are sold individually - a quantity of 2 is required per vehicle (sold as a pair when ordered in qty of 2)
• Lift range of 0-3" is achieved when paired with appropriate front coilovers and rear coil springs
• Recommended for everyday street driving and weekend off-road use - for more extreme off-road applications, consider the ICON V.S. 2.5 Aluminum Series rear shock
• Service rebuild kit available: ICON part number 202002 (2.0 IFP Rebuild Kit)
• Requires recalibration of Advanced Driver Assistance Systems (ADAS) after installation

Features

• Vehicle-specific valving tuned by ICON engineers specifically for the 2025-2026 Toyota 4Runner platform for optimized on- and off-road damping performance
• Nitrogen charged monotube design with internal reservoir delivers consistent damping and superior heat dissipation compared to stock twin-tube shocks
• One-piece linear/digressive piston design for smooth, progressive damping through the full range of suspension travel
• 6063 anodized aluminum body and reservoir tubing for excellent corrosion resistance, heat dissipation, and long-term durability
• 5/8" chrome-plated, induction-hardened steel shaft resists corrosion, pitting, and bending under hard use
• Polyurethane bushings and forged steel mounting stems provide OE-style factory fitment with no modifications required
• 100% rebuildable and re-tunable - serviced using ICON rebuild kit #202002
• Nitrile rubber top-out bumper for noise-free operation at full droop

Specifications

• Position: Rear
• Lift Range: 0-3" (with compatible front coilovers and rear springs)
• Body Diameter: 2.0" (6063 Anodized Aluminum)
• Shaft Diameter: 5/8" (0.625") Chrome-Plated Hardened Steel
• Shock Stroke: 10.4"
• Compressed Length: 16.1"
• Extended Length: 26.5"
• Reservoir Type: Internal
• Damping Adjustment: None (Fixed Valving)
• Upper Mount Type: Stem (M12 x 1.25 Thread)
• Lower Mount Type: Eyelet
• Bushing Material: Polyurethane (upper), Rubber (lower)
• Shock Oil: Premium Grade 5WT
• Country of Origin: United States
• UPC: 00840103434957
• Rebuild Kit: ICON #202002 (2.0 IFP Rebuild Kit)

Included Components

• 1x V.S. 2.0 Aluminum Series Rear Shock Absorber with Internal Reservoir
• Note: 2 units required per vehicle - order quantity of 2

Product Description

The ICON 56523 is a vehicle-specific V.S. 2.0 Aluminum Series rear shock absorber engineered for the 2025-2026 Toyota 4Runner. Designed as a cost-effective performance upgrade over the OE twin-tube shocks, this monotube internal reservoir unit delivers noticeably improved ride quality and suspension control both on and off road. ICON's engineers custom-tuned the valving specifically for the 6th Gen 4Runner's suspension geometry and weight characteristics, ensuring the shock performs optimally across the full 0-3" lift range when paired with ICON front coilovers and rear coil springs.

The 6063 anodized aluminum body provides superior heat dissipation and corrosion resistance, while the 5/8" chrome-plated hardened steel shaft resists the wear and corrosion that comes with trail use. Polyurethane bushings and forged steel mounting stems deliver OE-style fitment with a direct bolt-on installation - no cutting or welding required. These shocks are sold individually, so a quantity of 2 must be ordered per vehicle. They are 100% rebuildable using ICON's #202002 rebuild kit, and fully re-tunable for those who want custom valving in the future. ADAS recalibration is required after installation.
