ICON K53068 Stage 8 0-3.5" Suspension System for 10-24 Toyota 4Runner/FJ Cruiser

Vehicle Fitment

• 2010-2024 Toyota 4Runner (4WD, Stage 8 Suspension System)
• 2010-2014 Toyota FJ Cruiser (4WD, Stage 8 Suspension System)
• Compatible with KDSS-equipped 4Runners with track bar included

Features

• ICON Vehicle Dynamics Stage 8 complete suspension system for maximum wheel travel
• Extended travel 2.5" coilover shocks with CDCV (Compression Damping Control Valve)
• Adjustable front lift from 0 to approximately 3.5" over stock
• Billet aluminum upper control arms with patented Delta Joints for articulation
• CNC machined rear adjustable upper and lower link arms with FK rod ends
• Adjustable rear track bar to realign the axle after lift
• 2" rear coil springs for level front-to-rear stance
• 2.5" Omega bypass remote reservoir rear shocks with adjustable compression/rebound

Specifications

• Brand: ICON Vehicle Dynamics
• Part Number: K53068
• System Type: Stage 8 Full Suspension Lift Kit
• Front Lift Range: ~0-3.5" over stock
• Rear Lift: ~2" over stock
• Shock Type: Remote reservoir coilovers with CDCV front and Omega bypass rear
• Control Arms: Billet aluminum with Delta Joint
• Link Arms: Adjustable billet aluminum rear upper/lower links
• Track Bar: Adjustable rear track bar included
• Installation: 100% bolt-on, no welding required

Included Components

• 2x ICON 2.5" extended travel rear reservoir coilover shocks
• Front CDCV 2.5" extended travel coilovers (adjustable)
• Billet aluminum Delta Joint upper control arms
• Billet rear upper and lower link arms
• Adjustable rear track bar
• 2" rear coil springs
• Complete suspension hardware

Product Description

The ICON K53068 Stage 8 Suspension System is a premium full suspension upgrade engineered for **Toyota 4Runner (2010-2024)** and **Toyota FJ Cruiser (2010-2014)** 4WD vehicles. Designed for serious drivers seeking exceptional wheel travel, damping control, and ride quality both on-road and off-road, this Stage 8 system combines extended travel remote reservoir coilovers with precision-tuned valving and adjustable lift heights up to approximately **3.5" over stock**. The externally adjustable CDCV front coilovers let you dial in compression damping on the fly to match terrain and load, while the remote reservoir rear shocks offer 28 settings of compression and rebound adjustment for precise tuning.

Billet aluminum upper control arms with ICON's patented Delta Joints deliver improved articulation and strength over stock arms, while adjustable rear upper and lower link arms with PTFE-lined FK rod ends allow on-vehicle length adjustment for correct pinion angles. An adjustable rear track bar ensures proper axle alignment after lift, and 2" rear coil springs help maintain a level stance front to rear. With 100% bolt-on installation and no welding required, this Stage 8 system is a complete solution for 4Runners and FJ Cruisers that demand upgraded suspension performance and capability.
