ICON 71705CP 3.0 Series Rear RR Shocks CDCV 0-2" for 2011-2026 GM 2500/3500 HD

Vehicle Fitment

• 2011-2026 Chevrolet Silverado 2500 HD (All Cabs, All Engines, 2WD/4WD) - Non-Cab & Chassis
• 2011-2026 Chevrolet Silverado 3500 HD (All Cabs, All Engines, 2WD/4WD, SRW) - Non-Cab & Chassis
• 2011-2026 GMC Sierra 2500 HD (All Cabs, All Engines, 2WD/4WD) - Non-Cab & Chassis
• 2011-2026 GMC Sierra 3500 HD (All Cabs, All Engines, 2WD/4WD, SRW) - Non-Cab & Chassis

Fitment Notes

• Does NOT fit Cab & Chassis models on any year or trim
• Compatible with 0-2" of rear lift over stock - lift height is based on a stock-equipped vehicle
• OEM wheels and tires fit with these shocks installed
• Recommended aftermarket wheels: ICON Alloys 17x8.5" w/ 5" backspace / 6mm offset; 18x9" or 20x9" w/ 5.25" backspace / 6mm offset
• Offset upper eyelet design allows direct bolt-in fitment to factory rear shock mounts - no modification required
• For fixed-valving rear shocks without CDCV, see ICON part number 71705P; for CDEV electronic version see 71705EP
• Shocks are fully serviceable and rebuildable

Features

• ICON Compression Damping Control Valve (CDCV) delivers 10 externally adjustable compression damping settings - from soft to hard - via a clearly engraved knob at the reservoir, tunable on-vehicle without disassembly
• 3.0" body diameter delivers 50% more piston surface area than ICON's 2.5 Series shocks for superior stability and vehicle control under demanding off-road and towing conditions
• ICON's internal Bump Zone increases damping by 20% as the shock approaches full compression - protecting against harsh bottom-outs under high-velocity impacts
• Increased internal oil volume and larger external surface area versus 2.5 Series provide superior heat dissipation and fade resistance during sustained hard use
• Offset upper eyelet engineering allows direct bolt-in fitment to factory rear shock mounts
• Cerakoted steel cylinders with 6061 aircraft-grade aluminum CNC machined components for maximum corrosion resistance and durability
• One-piece linear compression/digressive rebound piston design with vehicle-specific valving for controlled, balanced performance
• 7/8" diameter induction-hardened, chrome-plated shock shaft; 100% rebuildable and re-tunable

Specifications

• Position: Rear
• Lift Range: 0-2" rear lift over stock
• Shock Body Diameter: 3.0"
• Shaft Diameter: 7/8" (0.875") Induction-Hardened, Chrome-Plated
• Reservoir Type: Remote Reservoir (Piggyback)
• Bump Zone: Yes - internal, increases damping 20% at full compression
• Damping Adjustment: CDCV - 10 externally adjustable compression damping settings, soft to hard
• CDCV Adjuster: Large engraved knob, 10 detented stops, on-vehicle adjustable
• Upper Mount Type: Offset Eyelet (fits factory rear shock mount)
• Piston Design: One-Piece Linear Compression / Digressive Rebound
• Body Material: Cerakoted Steel Cylinders with 6061 Aircraft-Grade Aluminum CNC Machined Components
• Shock Oil: Premium Grade 5WT
• Shipping Weight: 41.0 lbs
• Shipping Dimensions: 31.0" L x 13.0" W x 7.0" D
• UPC: 840103436326
• Country of Origin: United States

Included Components

• 2x V.S. 3.0 Series Rear Remote Reservoir Shock Absorbers with CDCV
• 2x Compression Damping Control Valves (CDCV)
• All required mounting hardware

Product Description

The ICON 71705CP is a vehicle-specific V.S. 3.0 Series rear remote reservoir shock pair with CDCV, engineered for the 2011-2026 Chevrolet Silverado 2500/3500 HD and GMC Sierra 2500/3500 HD (non-cab & chassis). At 3.0" in body diameter, these shocks deliver 50% more piston surface area than ICON's 2.5 Series rear options - providing greater stability, improved vehicle control, and significantly better heat dissipation for drivers who tow, haul heavy loads, or push their HD truck hard off-road. The Cerakoted steel cylinder construction provides excellent long-term corrosion resistance in demanding work and trail conditions, while the offset upper eyelet allows the shocks to bolt directly into the factory rear mounting location.

The CDCV adds 10-position externally adjustable compression damping - fine-tunable on-vehicle with a clearly engraved knob at the reservoir - allowing precise adjustment from soft street cruising to hard off-road damping with no disassembly required. ICON's integrated internal Bump Zone adds 20% more damping force as the shock nears full compression, preventing harsh bottom-outs under high-velocity hits. These shocks are compatible with 0-2" of rear lift over stock and are 100% rebuildable and re-tunable for long-term serviceability. Note: does not fit cab & chassis configurations on any year or trim.
