HKS S-Type Oil Cooler Kit for Toyota 86/BRZ FA20 S/C 15004-AT111

Vehicle Fitment

• 2012-2016 Toyota 86/FR-S (ZN6)
• 2012-2016 Subaru BRZ (ZC6)

Fitment Notes

• Designed for engines equipped with the HKS GT Supercharger or Bolt-on Turbo system - confirmed compatible with the HKS GT2 Supercharger Pro kit and GTIII-RS/GT4525 Bolt-on Turbo kits
• Requires minor modification to the radiator support and plastic resin covers
• Not confirmed for 2017+ "Kouki" facelift models or automatic transmission vehicles

Features

• Fender-mount installation with a 15-row black-finished oil cooler core
• Maintains stable oil temperatures around 110°C even under sustained track conditions, versus factory temperatures that can exceed 140°C during spirited driving
• Purpose-built for forced-induction FA20 engines requiring precise oil temperature management
• Recommended for vehicles tuned with GT superchargers or upgraded turbines, and for circuit use

Specifications

• Core: 15-row, black finish
• Mounting: Inner fender
• Application: Supercharged/Turbocharged FA20 only

Included Components

• 1x Oil Cooler Core
• Mounting Hardware and Piping

Product Description

The HKS 15004-AT111 is an S-Type black oil cooler kit built for the 2012-2016 Toyota 86/FR-S and Subaru BRZ, specifically for FA20 engines running forced induction via HKS's GT Supercharger or Bolt-on Turbo systems. Its 15-row core mounts to the inner fender and is designed to keep oil temperatures stable around 110°C, well below the 140°C+ levels the factory system can reach under sustained track driving.

This kit is purpose-built for supercharged or turbocharged applications where precise oil temperature control becomes critical, and is confirmed compatible with HKS's own GT2 Supercharger Pro and GTIII-RS/GT4525 turbo kits. Installation requires minor modification to the radiator support and plastic resin covers, and fitment has not been confirmed for 2017+ "Kouki" facelift models or automatic transmission vehicles.
