H&R 4075741 TRAK+ 20mm DR Wheel Spacers for 2014-2019 BMW X5 F15/F85 X6 F16/F86

Vehicle Fitment

• 2014-2018 BMW X5 xDrive35i (F15, 3.0L I6, AWD)
• 2014-2018 BMW X5 xDrive35d (F15, 3.0L I6 Diesel, AWD)
• 2014-2018 BMW X5 xDrive50i (F15, 4.4L V8, AWD)
• 2015-2018 BMW X5 M (F85, 4.4L V8 Twin-Turbo, AWD)
• 2014-2019 BMW X6 xDrive35i (F16, 3.0L I6, AWD)
• 2014-2019 BMW X6 xDrive50i (F16, 4.4L V8, AWD)
• 2015-2019 BMW X6 M (F86, 4.4L V8 Twin-Turbo, AWD)

Fitment Notes

• DR Series: spacer fits between the wheel and hub - longer wheel bolts required and must be ordered separately
• Verify bolt head type (taper or round) and required extra length before ordering replacement bolts
• Sold as a pair (2 spacers); 2 pairs required for all four corners
• Thread pitch: M14x1.25
• Not compatible with steel wheels - alloy/aluminum wheels only
• TUV approved for F15/F85 and F16/F86 platforms (certificates 132XT0246, 152XT0084, 152XT0205)
• Silver version; black anodized version available as part number 4075741SW

Features

• Pushes wheels outward 20mm per side (40mm per axle) for a wider, more flush stance and reduced fender gap
• Hubcentric design includes new hub lip matching the 74mm center bore - eliminates vibration and ensures precise wheel centering at all speeds
• DR Series slip-fit installation - spacer fits directly between wheel and hub with no hub modification required
• Lowers the roll center for improved lateral stability and reduced body lean under cornering loads
• Manufactured from H&R's proprietary aluminum/magnesium alloy - up to 70% lighter than comparable steel spacers
• Hard anodized finish provides surface hardness and corrosion resistance for long-term durability
• Compatible with OEM and aftermarket alloy wheels on the BMW 5x120 / 74mm CB specification
• 100% engineered and manufactured in Germany to ISO 9001 certified standards; TUV approved

Specifications

• Part Number: 4075741
• Series: TRAK+ DR
• Thickness: 20mm per spacer
• Bolt Pattern: 5x120
• Center Bore: 74mm
• Thread Pitch: M14x1.25
• Finish: Silver hard anodized
• Material: Proprietary aluminum/magnesium alloy
• Track Widening: 20mm per side (40mm total per axle)
• Position: Front and/or Rear (sold as pair per axle)
• TUV Certificates: 132XT0246, 152XT0084, 152XT0205

Included Components

• 2x H&R TRAK+ DR 20mm Wheel Spacers

Product Description

The H&R TRAK+ 4075741 is a 20mm DR Series wheel spacer purpose-built for the BMW X5 (F15/F85) and X6 (F16/F86) platforms. Featuring the 5x120 bolt pattern and 74mm center bore specific to these F-chassis SAV/SAC models, these spacers push each wheel 20mm outward from the hub, closing the gap between the tire and fender for a wider, more purposeful stance. The included new hubcentric lip ensures the wheel seats precisely on the spacer face, delivering vibration-free performance at all speeds without the compromise of a non-hubcentric universal spacer.

As a DR Series spacer, this unit fits directly between the wheel and hub - requiring longer wheel bolts that must be ordered separately. Before purchasing replacement bolts, confirm whether your wheels use taper-seat or round-head bolts and measure the additional length required. Built from H&R's proprietary aluminum/magnesium alloy and hard anodized for durability, these spacers are both lightweight and TUV approved for the F15, F85, F16, and F86 platforms. Sold as a pair for one axle - order two pairs for a full four-corner installation. The black anodized version is available as part number 4075741SW.
