H&R 40356330 TRAK+ 20mm DR Wheel Spacers for 2017-2024 Volvo S60 V60 S90 XC60

Vehicle Fitment

• 2019-2024 Volvo S60 (Gen III / 224 - T5, T6, T8 Recharge; Momentum, R-Design, Inscription, AWD/FWD)
• 2017-2024 Volvo S90 (Gen II / 234 - T5, T6, T8 Recharge; Momentum, R-Design, Inscription, AWD/FWD)
• 2019-2024 Volvo V60 (Gen II / 225 - T5, T6, T8 Recharge; Momentum, R-Design, Inscription, AWD/FWD)
• 2017-2024 Volvo V60 Cross Country (Gen II / 225 - B5, B6; AWD)
• 2017-2024 Volvo V90 (Gen II / 235 - T5, T6, T8 Recharge; Momentum, R-Design, Inscription, AWD/FWD)
• 2017-2024 Volvo V90 Cross Country (Gen II / 236 - T5, T6; AWD)
• 2019-2024 Volvo XC40 (536 - T4, T5, B4, B5; Momentum, R-Design, Inscription, AWD/FWD)
• 2018-2024 Volvo XC60 (Gen II / 246 - T5, T6, T8 Recharge; Momentum, R-Design, Inscription, AWD/FWD)

Fitment Notes

• DR Series: spacer fits between the wheel and hub - longer wheel bolts required and must be ordered separately
• Verify bolt head type and required additional length before purchasing replacement bolts (M14x1.5 thread pitch)
• Sold as a pair (2 spacers); 2 pairs required for all four corners
• Not compatible with steel wheels - alloy/aluminum wheels only
• Turn the wheel by hand after installation to confirm no brake or suspension contact before driving
• Alignment check recommended after installation
• Silver version; no black anodized version currently listed for this part number
• TUV approved for S60 III, V60 II, S90 II, V90 II (incl. Cross Country), XC40, and XC60 II platforms

Features

• Pushes wheels outward 20mm per side (40mm per axle) for a wider, more flush stance and reduced fender gap
• Hubcentric design with 63.3mm full-contact hub face eliminates vibration and ensures precise wheel centering at all speeds
• DR slip-fit installation - spacer seats directly between wheel and hub using longer OEM-style wheel bolts (purchased separately)
• Lowers the vehicle's roll center for improved lateral stability and reduced body lean in corners
• Manufactured from H&R's proprietary aluminum/magnesium alloy - up to 70% lighter than comparable steel spacers
• Hard anodized silver finish provides surface hardness and long-term corrosion resistance
• Compatible with OEM and aftermarket alloy wheels on the Volvo SPA/CMA 5x108 / 63.3mm CB specification
• 100% engineered and manufactured in Germany to ISO 9001 certified standards; TUV approved

Specifications

• Part Number: 40356330
• Series: TRAK+ DR
• Thickness: 20mm per spacer
• Bolt Pattern: 5x108
• Center Bore: 63.3mm
• Thread Pitch: M14x1.5
• Finish: Silver hard anodized
• Material: Proprietary aluminum/magnesium alloy
• Track Widening: 20mm per side (40mm total per axle)
• Position: Front and/or Rear (sold as pair per axle)
• TUV Certificates: 182XT0070 (S90/V90), 182XT0204 (XC40), 182XT0205 (XC60 II), 192XT0146 (S60/V60), 50600229502 (S90/V90), 50600234302 (XC40), 50600253102 (S60/V60), 50600256202 (XC60 II)

Included Components

• 2x H&R TRAK+ DR 20mm Silver Wheel Spacers

Product Description

The H&R TRAK+ 40356330 is a 20mm DR Series wheel spacer precision-engineered for Volvo's modern SPA and CMA platform vehicles - including the S60 III, S90 II, V60 II, V90 II, V90 Cross Country, XC40, and XC60 II. Sharing the 5x108 bolt pattern and 63.3mm center bore used across Volvo's current lineup, this spacer integrates with the factory hub geometry via a hubcentric full-contact face, ensuring vibration-free performance without compromise. As a DR Series spacer, it seats between the wheel and hub and requires longer M14x1.5 wheel bolts - sold separately - to complete the installation.

Each spacer moves the wheel 20mm outward, widening the total track by 40mm per axle for a stance that better fills the fender arch and eliminates the stock gap common on Volvo's conservatively offset factory wheel setups. Beyond aesthetics, the wider track lowers the roll center and improves lateral stability in corners. Built from H&R's proprietary aluminum/magnesium alloy, these spacers are lightweight, hard anodized for durability, and TUV approved across all covered Volvo SPA and CMA platforms. Sold as a pair - order two pairs for a complete four-corner installation.
