Gibson 619710 Cat-Back Exhaust for 1989-1994 Ford Ranger 2.3L/3.0L/4.0L

Vehicle Fitment

• 1989-1994 Ford Ranger (Extended Cab, 6-ft Bed, 2WD/4WD, 2.3L I4, 3.0L V6, 4.0L V6)
• 1989-1992 Ford Ranger Custom (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1990 Ford Ranger S Plus (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1991-1993 Ford Ranger Sport (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1989-1994 Ford Ranger STX (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1989-1994 Ford Ranger XLT (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1993-1994 Ford Ranger XL (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)
• 1994 Ford Ranger Splash (Extended Cab, 6-ft Bed, 2WD/4WD, applicable engines)

Fitment Notes

• Designed for Extended Cab Rangers with the 72-inch/6-ft bed configuration.
• Compatible with applicable 2WD and 4WD configurations.
• Regular Cab and 7-ft bed applications are not included in the verified fitment for this part number.
• 1989-1994 applications use the specified 2.3L, 3.0L, or 4.0L engine configurations according to year availability.
• Different Ranger cab/bed configurations use separate Gibson part numbers.

Features

• Gibson Swept-Side cat-back single exhaust system.
• 2.50-inch 409 stainless steel mandrel-bent tubing.
• Stainless steel SuperFlow baffled and chambered muffler.
• Muffler uses no internal packing.
• Designed for an aggressive exhaust sound with minimal interior drone.
• 3-inch polished T-304 stainless steel slash-cut tip.
• Single-side exit behind the rear tire.
• Mandrel-bent tubing promotes smoother exhaust flow.
• Designed to improve low-RPM torque and horsepower.
• Factory-style hangers and clamps support bolt-on installation.
• No welding is required for the intended installation.
• Backed by Gibson's limited lifetime warranty.

Specifications

• Brand: Gibson Performance Exhaust
• Part Number: 619710
• System Type: Cat-Back Single Exhaust
• Vehicle: Ford Ranger
• Years: 1989-1994
• Engines: 2.3L I4, 3.0L V6, 4.0L V6
• Drivetrain: 2WD/4WD
• Cab: Extended Cab
• Bed: 72-inch/6-ft Bed
• Tubing Diameter: 2.50 inches
• Tubing Material: 409 Stainless Steel
• Muffler: SuperFlow Baffled and Chambered
• Muffler Dimensions: 6-inch Round x 19-inch Long
• Muffler Inlet/Outlet: 2.50-inch Offset
• Tip: 3-inch Polished T-304 Stainless Steel Slash-Cut
• Exit Position: Behind Rear Tire

Included Components

• 1x Stainless Steel Headpipe with Flange
• 1x Stainless Steel SuperFlow Muffler
• 1x Stainless Steel Over-Axle Pipe
• 1x Stainless Steel Turnout Pipe
• 3x 2.50-inch Clamps
• 1x 3-inch Stainless Steel Exhaust Tip

Product Description

The Gibson 619710 is a Swept-Side cat-back single exhaust system designed for 1989-1994 Ford Ranger Extended Cab models with the 72-inch/6-ft bed. It is engineered for applicable 2WD and 4WD trucks using the 2.3L I4, 3.0L V6, or 4.0L V6 engines. The system uses 2.50-inch 409 stainless steel mandrel-bent tubing and a stainless SuperFlow muffler to improve exhaust flow while producing a deeper, more aggressive exhaust tone.

The baffled and chambered muffler uses no internal packing and is designed to minimize interior drone while supporting improved low-RPM torque and horsepower. Exhaust exits behind the rear tire through a polished 3-inch T-304 stainless steel slash-cut tip. The kit includes the required exhaust pipes, muffler, clamps, tip, and factory-style mounting components for a straightforward bolt-on installation.
