FOX 985-62-000 2.0 Perf Snap Ring Front Coil-Over for 16-23 Toyota Tacoma

Vehicle Fitment

• 2016-2023 Toyota Tacoma (Front, 2WD/4WD, 0-2" Lift/Level)

Features

• FOX 2.0 Performance Series Snap Ring Coil-Over IFP front shock
• Internal Floating Piston (IFP) mono-tube design for consistent damping
• Custom-molded spring seat reuses factory coil springs & hardware
• 3 preset ride height settings: 0", 1", 2" of lift
• Impact-extruded 6061-T6 aluminum body for heat dissipation & durability
• Clear anodized finish resists corrosion and wear
• Race-developed high-flow piston valving for enhanced control
• Direct-fit front application for Tacoma trucks (no spring included)

Specifications

• Part Number: 985-62-000
• Series: 2.0 Performance Series
• Position: Front coil-over shock absorber
• Extended Length: ~22.09" (56.1 cm)
• Compressed Length: ~17.30" (43.9 cm)
• Stroke/Travel: ~4.79" (12.2 cm)
• Body Diameter: 2.0" (50.8 mm)
• Mounts: Stem top / eyelet bottom
• Adjustable Lift: 0-2" via snap ring preload settings

Included Components

• 1x Front coil-over shock (985-62-000)
• 1x Custom molded spring seat (for reuse of stock spring)
• Installation hardware reuse: factory coil spring & mounting hardware

Product Description

The FOX 985-62-000 2.0 Performance Series Snap Ring Front Coil-Over is a vehicle-specific suspension upgrade designed for 2016-2023 Toyota Tacoma trucks. Engineered with a 2.0" impact-extruded 6061-T6 aluminum body and an Internal Floating Piston (IFP) design, this coil-over shock separates nitrogen from oil for consistent damping performance on- and off-road. Its custom-molded spring seat allows you to reuse the factory coil springs and hardware, cutting costs while improving ride quality and control.

With three preset ride height settings (0", 1", or 2" of lift), the 985-62-000 lets you tune Tacoma front ride height and performance without new springs. The race-developed piston valving enhances handling and smoothness over rough terrain, making this snap ring coil-over ideal for owners looking to level their ride or gain mild lift with retained factory components. Sold individually, this front coil-over is a direct-fit solution that boosts suspension performance while keeping installation straightforward.
