Eibach E86-82-109-01-22 ProTruck-Lift Stage 2 0-3" Lift for 25-27 4Runner TRD

Vehicle Fitment

• 2025-2027 Toyota 4Runner TRD -- 2.4L Turbo Hybrid 4WD
• 2025-2027 Toyota 4Runner TRD Off-Road -- 2.4L Turbo Hybrid 4WD

Fitment Notes

• 6th Gen 4Runner (N500) only -- 2.4L Turbo Hybrid 4WD models
• TRD and TRD Off-Road trims only
• Front out-of-box height is set level with OE rear spring
• Preload must be added to match Eibach rear spring height
• Do not exceed max lift height -- poor ride quality will result
• Exact lift heights may vary with vehicle package and weight distribution
• Eibach does not guarantee fitment, height, or warranty on unlisted applications

Features

• Stage 2 system -- Pro-Truck-Coilover 2.0's + Rear Sport Shocks
• Front lift: +0-3" (fully adjustable via threaded spring perch)
• Rear lift: +1.5"
• ERO Off-Road Race Spring equipped and compatible
• 46mm piston monotube design with nitrogen-filled variable force valving
• Anodized 6061-T6 billet aluminum coilover mounts
• Individually dyno tested for matched performance and reliability
• Heavy duty bushing system -- cycle tested
• Works with factory control arms -- no accelerated wear to ball joints
• Engineered, tested, and manufactured by Eibach in the USA
• 2-year warranty

Specifications

• System: PRO-TRUCK-LIFT Stage 2
• Contents: 2x front coilovers + 2x rear shocks
• Front coilovers: Pro-Truck-Coilover 2.0
• Rear shocks: Pro-Truck Sport Shocks
• Front lift range: 0-3" (adjustable)
• Rear lift: +1.5"
• Piston diameter: 46mm
• Damper design: Monotube
• Valving: Nitrogen-filled variable force
• Coilover mount material: 6061-T6 billet aluminum, anodized
• Spring compatibility: ERO Off-Road Race Springs
• Country of Origin: USA
• Warranty: 2-year

Included Components

• 2x Pro-Truck-Coilover 2.0 front coilovers (pre-assembled)
• 2x Pro-Truck Sport rear shocks
• Spanner wrench for on-vehicle height adjustment

Product Description

The Eibach E86-82-109-01-22 is a PRO-TRUCK-LIFT Stage 2 suspension system engineered specifically for the 2025-2027 Toyota 4Runner TRD and TRD Off-Road with the 2.4L Turbo Hybrid 4WD powertrain (6th Gen N500). The Stage 2 system pairs Eibach's Pro-Truck-Coilover 2.0 front coilovers with Pro-Truck Sport rear shocks, delivering 0-3" of adjustable front lift and 1.5" of rear lift. The threaded front spring perch allows fine-tuning of ride height on the vehicle without disassembly.

Front coilovers use a 46mm monotube piston with nitrogen-filled variable force valving and anodized 6061-T6 billet aluminum mounts. Each unit is individually dyno tested for matched corner performance. The system is ERO Off-Road Race Spring equipped and compatible, and is designed to work with factory control arms to prevent accelerated ball joint wear. Coilovers are pre-assembled and install without drilling. Engineered, tested, and manufactured by Eibach in the USA. Backed by a 2-year warranty.
