EBC S9KR1194 Rear Brake Kit for 2006-2013 Mazda 6 2.3L/2.5L/3.0L/3.7L

Vehicle Fitment

• 2006-2009 Ford Fusion (S, SE, SEL; 2.3L I4 or 3.0L V6; FWD)
• 2006-2010 Mercury Milan (Base, Premier; 2.3L I4 or 3.0L V6; FWD)
• 2011 Mercury Milan (Base, Hybrid, Premier; 2.5L I4 or 3.0L V6; FWD)
• 2007-2012 Lincoln MKZ (Base; 3.5L V6; FWD)
• 2011-2012 Lincoln MKZ (Hybrid; 2.5L I4 Hybrid; FWD)
• 2006 Lincoln Zephyr (Base; 3.0L V6; FWD)
• 2006-2013 Mazda 6 (i, GS; 2.3L I4 or 2.5L I4; FWD)
• 2006-2013 Mazda 6 (S, GT; 3.0L V6 or 3.7L V6; FWD)

Fitment Notes

• Rear brake application only.
• Kit is for vehicles using the 280 mm solid rear rotor configuration.
• Ford Fusion applications are limited to the 2006-2009 generation listed above.
• Mercury Milan applications are limited to 2006-2011 model years listed above.
• Lincoln MKZ applications cover 2007-2012, with hybrid applications specifically identified for 2011-2012.
• 2006 Lincoln Zephyr is a separate legacy application and should not be omitted when cataloging this part.
• Mazda 6 applications cover the 2006-2013 model years shown in the validated catalog data.
• All listed applications use front-wheel drive.
• Verify the factory rear rotor dimensions before installation because brake configurations can vary by application.

Features

• EBC Stage 9 Yellowstuff and USR rear brake kit.
• DP41766R Yellowstuff high-friction rear brake pads.
• USR1197 Ultimax Sport fine-slotted rear rotors.
• 280 mm rear rotor diameter.
• Solid cast-iron rotor construction.
• 10 mm nominal rotor thickness.
• 5-bolt mounting configuration.
• Fine-slotted friction surface helps evacuate water, dust and friction gases.
• Geomet anti-rust coating helps protect exposed rotor surfaces from corrosion.
• Yellowstuff aramid-fiber friction material is designed for high-friction performance use.
• EBC Brake-In coating supports faster initial pad seating and bedding.
• Designed for performance street, towing and street/track-event applications.

Specifications

• Brand: EBC Brakes
• Part Number: S9KR1194
• Series: S9 Yellowstuff Pad and USR Sport Slotted Rotor Kit
• Position: Rear
• Pad Part Number: DP41766R
• Rotor Part Number: USR1197
• Rotor Quantity: 2x
• Rotor Diameter: 280 mm
• Rotor Thickness: 10 mm new
• Rotor Minimum Thickness: 9 mm
• Rotor Height: 40 mm
• Rotor Center Bore: 72 mm
• Rotor Mounting Pattern: 5 bolt holes
• Rotor PCD: 114.3 mm
• Rotor Construction: Solid cast iron
• Rotor Style: Fine slotted
• Rotor Finish: Geomet anti-rust coating
• Pad Material: Aramid fiber

Included Components

• 1x EBC DP41766R Yellowstuff rear brake pad set
• 2x EBC USR1197 rear brake rotors

Product Description

The EBC S9KR1194 Stage 9 Rear Brake Kit combines DP41766R Yellowstuff high-friction brake pads with two USR1197 Ultimax Sport fine-slotted rear rotors. The kit is designed for compatible Ford Fusion, Mercury Milan, Lincoln MKZ/Zephyr and Mazda 6 applications using the specified 280 mm solid rear brake configuration.

The USR1197 rotors feature a 280 mm diameter, 10 mm new thickness, 9 mm minimum thickness, 40 mm height and 72 mm center bore with a 5x114.3 mm mounting pattern. The solid cast-iron rotors use a fine-slotted friction surface designed to help clear water, dust and friction gases while the Geomet coating provides corrosion protection on exposed surfaces.

The DP41766R Yellowstuff pads use EBC's high-friction aramid-fiber compound and Brake-In coating to support strong braking response and faster bedding. S9KR1194 is a vehicle-specific rear brake package, so the vehicle's year, engine, trim, drivetrain and factory rear rotor configuration should be confirmed before installation.
