EBC S4KF1937 Redstuff Front Brake Kit for 2019-2023 Toyota Corolla 2.0L

Vehicle Fitment

• 2019 Toyota Corolla (SE, XSE; 2.0L I4; FWD; Hatchback; 283mm front vented brakes)
• 2020-2022 Toyota Corolla (SE, SE Nightshade, XSE; 2.0L I4; FWD; Hatchback; 283mm front vented brakes)
• 2023 Toyota Corolla (SE, XSE; 2.0L I4; FWD; Hatchback; 283mm front vented brakes)

Fitment Notes

• Front brake kit for the 283mm x 22mm vented front rotor configuration.
• Verified applications are limited to the Corolla Hatchback SE, XSE, and applicable SE Nightshade trims listed above.
• 2020-2022 SE Nightshade fitment is included.
• Do not apply to Corolla configurations using a different front brake package.
• Verify the factory front rotor dimensions and caliper configuration before installation.

Features

• EBC S4 Stage 4 Redstuff Ceramic front brake kit
• Redstuff ceramic-aramid performance brake pads
• Low-dust friction compound
• Fully shimmed, slotted, and chamfered brake pads
• EBC Brake-in coating promotes rapid pad seating
• USR Sport fine-slotted vented rotors
• G3000 cast-iron rotor construction
• Geomet anti-corrosion rotor coating
• Precision-machined rotor construction
• Designed for spirited street and highway driving
• Direct-fit configuration for the compatible factory brake system
• Designed to provide performance braking with reduced dust

Specifications

• Brand: EBC Brakes
• Part Number: S4KF1937
• Product Type: Front Brake Pad and Rotor Kit
• Position: Front
• Rotor Diameter: 283mm
• Rotor Thickness: 22mm
• Minimum Rotor Thickness: 19mm
• Rotor Height: 46mm
• Center Bore: 55mm
• PCD: 100mm
• Rotor Bolt Holes: 5
• Rotor Type: Vented
• Rotor Style: USR fine-slotted
• Rotor Material: Cast Iron
• Rotor Finish: Geomet coated
• Pad Compound: Redstuff Ceramic-Aramid
• Pad FMSI: D2176
• Kit Components: DP33099C + USR7808

Included Components

• 2x EBC USR7808 Front Slotted Vented Brake Rotors
• 1x EBC DP33099C Redstuff Ceramic Front Brake Pad Set
• 1x Caliper Lubricant Package

Product Description

EBC S4KF1937 is a Stage 4 front brake kit combining Redstuff ceramic-aramid performance pads with EBC USR Sport fine-slotted vented rotors. The kit is designed for selected 2019-2023 Toyota Corolla Hatchback applications equipped with the 283mm front brake configuration. It provides a performance-oriented upgrade while maintaining the compatible factory brake-system architecture.

The Redstuff pads use ceramic-aramid friction material and feature shims, slots, chamfers, and EBC Brake-in coating to promote rapid bedding. The matching USR7808 rotors measure 283mm in diameter, 22mm thick, and 46mm high, with a 55mm center bore, 100mm PCD, and five mounting holes. The cast-iron rotors use EBC's fine-slotted design and Geomet coating for corrosion protection.

The kit is supplied as a complete front-axle package containing two USR7808 rotors, one DP33099C Redstuff pad set, and caliper lubricant. Verified catalog data covers the 2019-2023 Corolla Hatchback SE and XSE, with SE Nightshade additionally confirmed for 2020-2022. Confirm the vehicle's exact front brake configuration before installation.
