EBC S4KR1561 Redstuff Rear Brake Kit for 2016-2020 Lexus IS300 2.0L/3.5L

Vehicle Fitment

• 2016-2017 Lexus IS300 (Base, F Sport; 3.5L V6; AWD; rear 310mm vented brake configuration)
• 2018-2020 Lexus IS300 (Base, F Sport; 2.0L Turbo I4 or 3.5L V6; RWD/AWD where equipped; rear 310mm vented brake configuration)

Fitment Notes

• Rear brake kit for the compatible 310mm vented rear rotor configuration.
• 2016-2017 IS300 applications are cataloged with the 3.5L V6; AWD is confirmed for these applications.
• 2018-2020 IS300 applications include 2.0L Turbo I4 and 3.5L V6 configurations, with RWD/AWD availability varying by year and trim.
• Verified trim coverage is Base and F Sport.
• Do not apply to an IS300 equipped with a different rear brake configuration without confirming rotor and pad dimensions.
• Some catalog records identify the supplied rotor as 309mm/310mm; verify the factory rear rotor specification before installation.

Features

• EBC Stage 4 Redstuff rear brake kit
• Redstuff low-dust ceramic brake pads
• Aramid-fiber-enhanced friction material with ceramic granules
• Fully shimmed, slotted, and chamfered pad construction
• EBC Brake-in coating promotes rapid pad seating
• USR Sport fine-slotted vented rear rotors
• G3000 cast-iron rotor construction
• Geomet anti-corrosion rotor coating
• Fine slots help evacuate brake gases and debris
• Designed for reduced brake dust compared with conventional performance compounds
• Direct-fit configuration for the compatible factory rear brake system
• Designed for performance street and spirited highway driving

Specifications

• Brand: EBC Brakes
• Part Number: S4KR1561
• Product Type: Rear Brake Pad and Rotor Kit
• Position: Rear
• Pad Compound: Redstuff Ceramic
• Pad Part Number: DP31586C
• Pad FMSI: D1113
• Rotor Part Number: USR7637
• Rotor Diameter: 310mm
• Rotor Thickness: 18mm
• Rotor Height: 67.4mm
• Center Bore: 62mm
• Rotor Bolt Holes: 5
• Rotor Type: Vented
• Rotor Style: USR Fine-Slotted
• Rotor Material: G3000 Cast Iron
• Rotor Finish: Geomet Coated

Included Components

• 2x EBC USR7637 Rear Slotted Vented Brake Rotors
• 1x EBC DP31586C Redstuff Ceramic Rear Brake Pad Set
• 1x Caliper Lubricant Package

Product Description

EBC S4KR1561 is a Stage 4 rear brake kit combining EBC Redstuff ceramic performance pads with USR Sport fine-slotted and vented rear rotors. The kit is cataloged for 2016-2020 Lexus IS300 Base and F Sport models and is designed around the compatible 310mm rear brake configuration. It provides a matched pad-and-rotor upgrade for performance-oriented street and spirited highway driving.

The DP31586C Redstuff pads use aramid-fiber-enhanced ceramic friction material with ceramic granules and incorporate shims, slots, chamfers, and EBC Brake-in coating for controlled bedding. The matching USR7637 rotors are cataloged at 310mm diameter, 18mm thickness, and 67.4mm height, with a 62mm center bore and five mounting holes. Their G3000 cast-iron construction and Geomet coating provide the specified rotor construction and corrosion protection.

The kit includes two USR7637 rear rotors, one DP31586C Redstuff pad set, and caliper lubricant. Verified application data covers the 2016-2017 3.5L V6 IS300 and the 2018-2020 2.0L Turbo I4 and 3.5L V6 IS300 configurations, with Base and F Sport trims listed. Because drivetrain availability varies by year, the vehicle's exact rear brake configuration should be confirmed before installation.
