EBC S13KR1438 Yellowstuff Rear Brake Kit for 2006-2013 Mazda 6 2.3L/3.7L

Vehicle Fitment

• 2006-2007 Mazda 6 (i, S, Mazdaspeed; 2.3L I4 or 3.0L V6; FWD)
• 2008 Mazda 6 (i, S, GS, GT; 2.3L I4 or 3.0L V6; FWD)
• 2009-2013 Mazda 6 (i, S; 2.5L I4 or 3.7L V6; FWD)
• 2006-2009 Ford Fusion (S, SE, SEL; 2.3L I4 or 3.0L V6; FWD)
• 2007-2010 Lincoln MKZ (Base; 3.5L V6; FWD/AWD where equipped)
• 2011-2012 Lincoln MKZ (Base, Hybrid; 2.5L I4 or 3.5L V6; FWD/AWD where equipped)
• 2006 Lincoln Zephyr (Base; 3.0L V6; FWD)
• 2006-2009 Mercury Milan (Base, Premier; 2.3L I4 or 3.0L V6; FWD)
• 2010-2011 Mercury Milan (Base, Premier, Hybrid; 2.5L I4 or 3.0L V6; FWD)

Fitment Notes

• Rear brake application only.
• Applications use the specified 280mm solid rear rotor configuration.
• Ford Fusion, Lincoln MKZ, Mercury Milan, and Lincoln Zephyr applications are separate legacy platform applications from Mazda 6.
• AWD availability applies only where factory-equipped on the applicable Lincoln MKZ configuration.
• No 2014 or newer Mazda 6, Fusion, MKZ, Milan, or Zephyr application is confirmed for this part.

Features

• EBC Stage 13 rear performance brake pad and rotor kit.
• Yellowstuff high-friction aramid-fiber brake pad compound.
• Designed for performance street, towing, and demanding driving applications.
• Pads are fully shimmed, chamfered, and slotted.
• EBC Brake-in coating promotes faster initial pad seating.
• RK-series rotors use an OE-style smooth/plain friction surface.
• Solid cast-iron rotor construction matches the specified rear brake configuration.
• Geomet anti-corrosion coating helps protect exposed rotor surfaces.
• Rotors are balanced and runout tested for smooth braking operation.
• Direct-fit configuration requires no changes to the stock brake setup when correctly matched.

Specifications

• Brand: EBC Brakes
• Part Number: S13KR1438
• Position: Rear
• Kit Type: Brake Pad and Rotor Kit
• Pad Part Number: DP41766R
• Rotor Part Number: RK1197
• Pad Compound: Yellowstuff
• Pad Material: Aramid Fiber
• FMSI Pad Number: D1161
• Rotor Diameter: 280mm
• Rotor Thickness: 10mm
• Rotor Height: 40mm
• Center Bore Diameter: 72mm
• Rotor Construction: Solid cast iron
• Rotor Surface: Smooth/plain
• Bolt Pattern: 5-lug
• Rotor Coating: Geomet anti-corrosion coating
• Quantity: 2-wheel rear axle set

Included Components

• 1x DP41766R Yellowstuff Rear Brake Pad Set
• 1x RK1197 Ultimax OE Style Smooth Solid Rear Disc Rotor 2-Wheel Set

Product Description

The EBC S13KR1438 is a Stage 13 rear brake upgrade combining EBC Yellowstuff high-friction brake pads with RK1197 smooth solid rear rotors. The kit is designed for selected Mazda, Ford, Lincoln, and Mercury applications using the specified 280mm rear brake configuration. The RK1197 rotor features a 10mm thickness, 40mm height, 72mm center bore, and 5-lug design.

The Yellowstuff pads use an aramid-fiber friction material engineered for strong performance in demanding street applications. They are fully shimmed, chamfered, and slotted and feature EBC Brake-in coating to assist with initial bedding. The RK1197 rotors use OE-style solid cast-iron construction, a smooth friction surface, Geomet anti-corrosion coating, and balanced/runout-tested manufacturing.

Verified applications span 2006-2013 Mazda 6 models, 2006-2009 Ford Fusion, 2007-2012 Lincoln MKZ, 2006 Lincoln Zephyr, and 2006-2011 Mercury Milan. Engine and trim availability varies by model year, so the vehicle's original rear rotor dimensions and brake configuration should be confirmed before installation.
