EBC S13KR1652 Rear Yellowstuff Pad & RK Rotor Kit for15-23 Subaru Legacy/Outback

Vehicle Fitment

• 2015-2023 Subaru Legacy (2.5 L H4, 3.6 L H6; all trims)
• 2015-2023 Subaru Outback (2.5 L H4, 3.6 L H6; all trims)
• 2016-2018 Subaru WRX (2.0 L H4 Turbo; Base/Limited/Premium)
• Kit requires rear disc brakes matching FMSI pad code D1808 and 5-bolt rotor hubs
• Fitment confirmed through 2023; 2024-2025 coverage unverified

Features

• GG-rated Yellowstuff aramid fiber pads - slotted, shimmed, chamfered, and Brake-In® coated
• Plain-face vented RK rotors (300 mm dia) with Thermic Black/Geomet anti-rust coating
• Rotors precision balanced and run-out tested for vibration-free braking
• Direct bolt-on rear kit - no modifications required
• ~30-40% increased braking performance over OEM rear pads
• Low dust output and rotor wear compared to aggressive compounds
• Includes caliper slide-pin lube packet for correct installation
• 1-year / 10,000-mile pad & 6-month / 10,000-mile rotor warranty (void if coating removed or used competitively)

Specifications

• Position: Rear axle only
• Rotor dia: 300 mm; Thickness: ~17 mm; Height: 46.35 mm; Center bore: 58 mm; 5-bolt pattern
• Pad code: FMSI D1808; aramid fiber compound
• Pad/rotor features: Slotted pads, chimfered & shimmed; rotors plain-faced, vented
• Rotor coating: Thermic Black/Geomet - must remain intact to preserve warranty
• Compatible with OEM rear calipers on listed Subaru models

Included Components

• 2x Rear Yellowstuff pads (FMSI D1808; slotted, shimmed, chamfered)
• 2x RK vented rear rotors (300 mm dia x ~17 mm thick, Thermic Black coated)
• 1x Caliper slide-pin lube packet

Product Description

The EBC S13KR1652 rear brake kit is an OE-style performance upgrade designed for Subaru Legacy, Outback, and WRX vehicles equipped with rear disc brakes (2015-2023). It combines GG-rated Yellowstuff pads - slotted, shimmed, chamfered, and Brake-In® coated - with precisely balanced 300 mm vented RK rotors featuring Thermic Black anti-rust coating, delivering around 30-40% more braking force while reducing dust and rotor degradation.

Installation is effortless with no modifications required. Rotors arrive pre-balanced and run-out tested; pads are optimized for fast bedding and low noise. A slide-pin lube packet is provided to ensure proper caliper function. Importantly, the Thermic Black coating must be preserved to maintain warranty coverage. The pad and rotor warrantied for up to 10,000 miles, voided if coating is removed or for competition use.

Fitment is confirmed through model year 2023; 2024-2025 coverage remains unverified at this time. Ideally suited for drivers seeking reliable, spirited street braking with OEM-level fitment. For balanced performance, pair this kit with a matching front Yellowstuff/RK Stage 13 kit.
