EBC RK2057X OE Premium Vented Front Rotors for 2015-2021 Porsche Macan S GTS

Vehicle Fitment

• 2015-2018 Porsche Macan S (95B), 3.0L Twin-Turbo V6, AWD
• 2015-2019 Porsche Macan Turbo (95B), 3.6L Twin-Turbo V6, AWD
• 2015-2021 Porsche Macan GTS (95B / 95B.2), 3.0L Twin-Turbo V6, AWD
• 2019-2021 Porsche Macan S (95B.2), 3.0L Twin-Turbo V6, AWD
• 2020-2021 Porsche Macan GTS (95B.2), 2.9L Twin-Turbo V6, AWD

Fitment Notes

• For standard cast iron brake systems only - does not fit vehicles equipped with Porsche Ceramic Composite Brakes (PCCB) or Porsche Surface Coated Brakes (PSCB)
• Does not fit the 2015-2021 Porsche Macan Base (2.0L I4) - base models use a smaller front rotor diameter and are not compatible
• Does not fit 2018 Macan Sport Edition - verify rotor diameter before ordering
• 2019+ Macan Turbo discontinued; the RK2057X covers Turbo fitment through 2019 model year only
• 2022+ Macan (95B.3 facelift) received revised powertrains and brake configurations - fitment not confirmed for 2022 or later
• Sold as a pair (2x rotors per set); always replace both front rotors simultaneously
• Verify PR code on door jamb sticker to confirm non-PCCB/PSCB brake configuration before ordering

Features

• Made from premium G3000 specification gray cast iron - the same OEM-grade material used in original Porsche factory rotors for optimal thermal performance and longevity
• Every rotor individually runout-inspected at the factory to tolerances under 0.05mm, guaranteeing zero rotor distortion and vibration-free braking straight from the box
• Silver-grey Geomet-style anti-corrosion coating applied immediately after machining at the casting plant - prevents pre-installation surface oxidation without any prep work required
• Direct OEM-spec replacement profile - no caliper, bracket, or hardware modifications needed for installation
• High carbon and silicone content iron formulation reduces brake shudder, heat cracking, and high-frequency vibration that causes squealing under spirited driving conditions
• Diamond-turned or cross-ground braking surface finish ensures precise, even pad contact for optimized bed-in and consistent wear from day one
• ECE R90 certified - EBC's disc rotors have passed the stringent European R90 brake standard, confirming OEM-equivalent or superior stopping performance
• Fully balanced and runout-tested for smooth, fade-free pedal feel in all driving conditions including extended spirited road use
• Compatible with EBC Ultimax2, Greenstuff, Redstuff, and Yellowstuff brake pad compounds for a fully matched, optimized braking upgrade

Specifications

• Position: Front
• Rotor Construction: Vented 1-Piece
• Rotor Style: Plain (smooth surface)
• Rotor Diameter: 360mm (14.17 in)
• Rotor Thickness: 36mm
• Hat Height: 52mm
• Bolt Holes: 5
• FMSI Pad Number: D1349
• Material: G3000 Gray Cast Iron
• Coating: Silver-Grey Geomet Anti-Rust Surface Coating
• Drivetrain Compatibility: AWD (all Macan variants are standard AWD)
• Certification: ECE R90 Approved

Included Components

• 2x EBC RK2057X Vented Front Brake Rotors (one per wheel)

Product Description

The EBC RK2057X is a premium OE-replacement front brake rotor engineered for the first-generation Porsche Macan (95B / 95B.2) equipped with standard cast iron brakes across the S, GTS, and Turbo trim levels. Built from G3000 specification gray cast iron - the same grade specified by Porsche for original equipment - these 360mm vented rotors are machined to tolerances tighter than 0.05mm and individually inspected for runout before leaving the factory. The result is a rotor that drops directly into place with zero shimming or caliper rework, delivering a vibration-free pedal feel from the very first stop.

EBC's silver-grey Geomet-style coating is applied at the point of casting, immediately after machining and washing, leaving no window for surface oxidation to form before installation. The coating naturally wears off the braking surface during the first few stops while protecting the hat, vanes, and non-contact areas from corrosion throughout the rotor's service life. The high-carbon iron formulation also helps dissipate heat more efficiently than lower-grade alternatives, resisting the brake fade and rotor warping that high-performance SUVs are prone to during spirited driving. EBC rotors are ECE R90 certified - a rigorous European standard that confirms the disc performs at or above original equipment levels.

These rotors are for Macan models equipped with standard steel brakes only. Vehicles optioned with Porsche Ceramic Composite Brakes (PCCB) or Porsche Surface Coated Brakes (PSCB) use different rotor designs and are not compatible. To confirm your brake configuration, check the PR code on the door jamb sticker or consult your Porsche dealer. Rotors are sold as a pair of two, covering both front corners. For best results, install with EBC Ultimax or Redstuff brake pads (FMSI D1349) and perform a proper bed-in with 5-10 progressive stops from highway speed to fully seat the pad and rotor surfaces.
