EBC RK1434 Vented Front Brake Rotors for 2013-2025 Ford Escape/Transit Connect

Vehicle Fitment

• 2013-2025 Ford Escape (SE/S/SEL/Titanium, 1.6L I4 Turbo, 4WD/AWD)
• 2013-2025 Ford Transit Connect (XL/Trend/Titanium, 1.6L & 2.0L I4)

Features

• OE-style vented design for efficient heat dissipation under load
• Precision-machined from high-carbon G3000 grey iron for OEM-level performance
• Black GEOMET/NITROTHERM® coating resists corrosion and enhances aesthetics
• Balanced to <0.05 mm for smooth, vibration-free spinning
• Thermic coating self-wears away in pad sweep area - no prep needed
• Direct bolt-on fitment for FMSI D1668 pads (Escape) and D1645 (Transit)
• Manufactured to meet or exceed OE spec (320 mm diameter, 25 mm thickness)
• Designed for everyday driving, towing, off-road commuter use

Specifications

• Position: Front
• Rotor Type: Vented
• Diameter: 320.04 mm
• Thickness: 25 mm (new)
• Height: 49 mm
• Bolt Pattern: 5-lug, 108 mm PCD
• Center Bore: 63.5 mm
• Material: G3000 grey iron, high carbon content
• Coating: Black GEOMET/NITROTHERM anti-corrosion finish
• Emissions-Legal: CARB/EPA compliant (OE replacement)

Included Components

• 2x EBC RK1434 front vented brake rotors

Product Description

The EBC RK1434 rotors are premium OE-style replacements engineered specifically for 2013-2025 Ford Escape and Transit Connect models with 1.6L or 2.0L I4 engines. Constructed from high-carbon G3000 grey iron and CNC-machined to under 0.05 mm run-out, these rotors deliver smooth, reliable braking performance with minimal noise and vibration.

Featuring a vented 320 mm diameter design and corrosion-resistant GEOMET/NITROTHERM coating, the RK1434 rotors are ideal for daily commuting, towing, and light off-road applications. They come ready to install - no coating removal required - and offer direct compatibility with FMSI D1668 (Escape) and D1645 (Transit Connect) pads. Emissions-legal and engineered to meet or exceed OEM specs, these rotors are the smart upgrade for drivers seeking long-lasting performance and peace of mind.
