CSF 7228 Half Radiator for 2003-2007 Mitsubishi Lancer Evo 7/8/9 2.0L Turbo AWD

Vehicle Fitment

• 2003-2007 Mitsubishi Lancer Evolution 7/8/9 (CT9A; 2.0L 4G63 Turbo, AWD)

Features

• 2-row, 42 mm high-performance all-aluminum core
• CSF B-Tube technology - ~15 % improved heat transfer
• Multi-louvered fins for enhanced airflow
• Adjustable top mounting bracket for easy alignment
• 2-way adjustable breather pipe for flexible hose routing
• Built-in 1/8" NPT temperature sensor port (plug included)
• 100 % TIG-welded full-aluminum construction
• Polished mirror-finish or satin-black (7228B) aesthetic option

Specifications

• Core thickness: 42 mm (1.65"), twin-row design
• Cooling tubes: 40, with B-Tube enhanced oval shape
• Fin height: 6.5 mm, multi-louvered
• Material: Full aluminum core and end tanks
• Dims: Half-size for Evo engine bay clearance
• Weight: ~9.8 lb (4.45 kg) - lightweight upgrade
• Inlet/outlet: OEM slip-on connections
• Pressure rated to OEM coolant system

Included Components

• 1x CSF 7228 radiator (polished or black finish)
• 1x Adjustable top mounting bracket
• 1x Adjustable breather pipe
• 1x Plug for unused NPT port (if no sensor installed)

Product Description

The CSF 7228 half-size radiator is custom-engineered for the 2003-2007 Mitsubishi Lancer Evo 7/8/9 (CT9A, 2.0L 4G63 turbo, AWD). Tailored for high-performance and space-restricted builds, its 2-row 42 mm aluminum core with CSF's B-Tube technology delivers ~15 % better heat transfer than standard oval tubes. The compact "half-rad" design provides vital clearance for forward-facing turbos and tight engine bays without sacrificing cooling efficiency or OEM fitment.

Featuring multi-louvered fins, a fully TIG-welded aluminum structure, adjustable mounting hardware, and a dedicated NPT port for optional temp sensors, the CSF 7228 ensures both performance and convenience. Engineered to work seamlessly with Evo-specific radiator fans and shrouds, it drops directly into factory locations. Offered in polished or satin-black finishes, it also enhances under-hood aesthetics.

Ideal for Evo owners engaging in track days, big-turbo setups, or aggressive driving, this radiator offers superior cooling under stress. Fitment is confirmed exclusively for Evo 7/8/9 models; no support for other vehicles. Ensure your build year and model match before ordering.
