Brembo KT00A59 Front Brake Pads & Rotor Kit 330mm for 01-12 Porsche 911 -996/997

Vehicle Fitment

• 2001-2005 Porsche 911 Turbo (996) 3.6L Twin-Turbo
• 2002-2005 Porsche 911 Carrera 4S (996) 3.6L
• 2005-2008 Porsche 911 Carrera S (997.1) 3.8L
• 2005-2008 Porsche 911 Carrera 4S (997.1) 3.8L
• 2006-2008 Porsche 911 Targa 4S (997.1) 3.8L
• 2009-2011 Porsche 911 Carrera S (997.2) 3.8L
• 2009-2011 Porsche 911 Carrera 4S (997.2) 3.8L
• 2009-2011 Porsche 911 Targa 4S (997.2) 3.8L
• 2011-2012 Porsche 911 Carrera GTS (997.2) 3.8L
• 2011-2012 Porsche 911 Carrera 4 GTS (997.2) 3.8L

Fitment Notes

• Front axle ONLY -- 330mm rotor diameter
• Models with standard iron brakes ONLY
• Does NOT fit models with PCCB (Porsche Ceramic Composite Brakes)
• Does NOT fit base Carrera or Carrera 4 with smaller front rotors
• Porsche OE rotor #: 99635140902 / 99635140903
• Porsche OE pad #: 99635194910 / 99735194902
• Companion rear kit: KT00A60

Features

• Brembo complete front brake pad and rotor kit
• Brembo Prime UV Coated rotors -- high carbon cast iron
• Patented Pillar Venting Technology (PVT) -- 40%+ improved crack resistance
• Cross-drilled rotor surface -- improved wet braking and heat dissipation
• UV coating -- solvent-free corrosion protection on all non-friction surfaces
• Brembo Prime Ceramic (NAO) brake pads -- low dust, low noise
• Chamfered pad edges for reduced noise
• Pre-burnished pad surface for smooth break-in
• Corrosion-resistant coated pad backing plate
• All hardware included -- ready for installation out of the box

Specifications

• Kit Part Number: KT00A59
• Brand: Brembo
• Type: Front disc brake pad and rotor kit
• Position: Front
• Rotor Part Number: 09.C877.11 (x2)
• Rotor Diameter: 330mm (12.99")
• Rotor Thickness: 34mm
• Rotor Min Thickness: 32mm
• Rotor Height: 69mm
• Rotor Type: Vented, cross-drilled, PVT
• Rotor Material: High carbon cast iron
• Rotor Surface Treatment: UV coated
• Bolt Holes: 5
• Center Bore: 98mm
• Pad Part Number: P65011N (x1 set)
• Pad Material: Ceramic (NAO)

Included Components

• 2x Brembo 09.C877.11 front brake rotors (left and right)
• 1x Brembo P65011N front ceramic brake pad set
• Fixing screw kit for rotor installation
• Stainless-steel hardware
• Brake lubricant

Product Description

The Brembo KT00A59 is a complete front disc brake pad and rotor kit for 2001-2012 Porsche 911 models equipped with 330mm front brakes, including the 996 Turbo, 996 Carrera 4S, and all 997-generation Carrera S, Carrera 4S, Targa 4S, and GTS variants. This kit pairs Brembo's Prime UV Coated cross-drilled rotors (09.C877.11) with Prime Ceramic (NAO) brake pads (P65011N) for a matched braking solution designed for comfort, low dust, and consistent stopping performance. The high carbon cast iron rotors feature Brembo's patented Pillar Venting Technology (PVT) for over 40% improved resistance to thermal cracking compared to conventional designs.

The solvent-free UV coating protects all non-friction surfaces from corrosion while delivering a clean, factory-quality appearance. The ceramic brake pads are specifically formulated for reduced brake dust and quiet operation with chamfered edges and pre-burnished friction surfaces for minimal break-in time. This kit fits models with standard iron brakes only -- does NOT fit vehicles equipped with Porsche Ceramic Composite Brakes (PCCB). For the companion rear brake kit, use Brembo KT00A60. Everything needed for a complete front brake service is included in the box -- rotors, pads, fixing screws, hardware, and lubricant.
