Brembo 09.7217.21 Rear Brake Rotors for 1995-2006 Jaguar XJ/XK

Vehicle Fitment

• 1995-2003 Jaguar Vanden Plas (Base/SC, 4.0L V8, RWD)
• 1995-1996 Jaguar XJ12 (Base, 6.0L V12, RWD)
• 1995-1997 Jaguar XJ6 (Base/L, 3.2L I6/4.0L I6, RWD)
• 1998-2003 Jaguar XJ8 (Base/L/Sport, 3.2L V8/4.0L V8, RWD)
• 1995-2003 Jaguar XJR (Base/100, 4.0L Supercharged V8, RWD)
• 1995-1996 Jaguar XJS (Base/2+2, applicable 4.0L I6/6.0L V12, RWD)
• 1997-2006 Jaguar XK8 (Base/Victory Edition, 4.0L/4.2L V8, RWD)
• 2000-2006 Jaguar XKR (Base/Silverstone/100/Victory Edition, 4.0L/4.2L Supercharged V8, RWD)

Fitment Notes

• Rear axle application only.
• Fitment is for the specified Jaguar rear braking configuration; verify the vehicle's original brake disc dimensions before ordering.
• 2003 XJ8 Sport applications are included where equipped with the compatible 305 mm rear rotor.
• 2006 XK8 Victory Edition and applicable XKR special editions require confirmation of the factory rear brake configuration.
• This rotor is not assigned to AWD applications; listed applications use rear-wheel drive.

Features

• Brembo Prime Line OE-equivalent replacement brake disc.
• Designed for the rear axle of compatible Jaguar applications.
• 305 mm outside diameter provides the specified braking surface.
• 20 mm nominal disc thickness matches the specified application.
• Ventilated construction supports heat dissipation during repeated braking.
• UV-painted surface treatment provides enhanced corrosion protection.
• Protective coating covers the disc hub and outer edges.
• Five-hole mounting configuration matches the specified Jaguar application.
• ECE R90 type-approved Brembo brake disc.
• OE-equivalent design requires no modifications for installation when correctly matched to the vehicle.

Specifications

• Brand: Brembo
• Part Number: 09.7217.21
• Product Line: Prime
• Product Type: Rear Brake Disc Rotor
• Position: Rear
• Outside Diameter: 305 mm
• Nominal Thickness: 20 mm
• Minimum Thickness: 18.5 mm
• Overall Height: 68 mm
• Centering Diameter: 74 mm
• Number of Mounting Holes: 5
• Brake Disc Type: Ventilated
• Surface Treatment: UV Coated
• Installation: No modifications required for the specified application
• Disc Tightening Torque: 103 Nm
• EAN: 8020584030943
• Replacement Part Number: Replaces Brembo 09.7217.10
• Comparable OE Numbers: C2C41251, JLM11904, JLM12428, JLM20342, MJA2692AA

Included Components

• 2x Brembo 09.7217.21 Brake Disc Rotors

Product Description

The Brembo 09.7217.21 Prime Brake Rotor is an OE-equivalent rear brake disc designed for compatible Jaguar XJ, XJS, XK8, XKR, and Vanden Plas applications. Measuring 305 mm in diameter and 20 mm thick, this ventilated rotor is engineered to restore the factory braking dimensions and thermal-management characteristics on vehicles using the specified rear brake configuration.

The rotor features Brembo's UV-painted corrosion-resistant treatment on the hub and outer edges, helping protect exposed areas from corrosion while providing a clean finished appearance. Its five-hole mounting pattern, 74 mm centering diameter, 68 mm overall height, and 18.5 mm minimum thickness are engineered around the specified Jaguar applications. Brembo also identifies the disc as ECE R90 type-approved.

Supplied as a pair of two rear rotors, the 09.7217.21 is intended for replacement of worn or deteriorated original rear discs. Before installation, verify the exact vehicle trim, engine, factory rear brake configuration, and rotor dimensions to ensure complete compatibility, particularly on special-edition and performance Jaguar models.
