Brembo 09.D532.13 Rear Co-Cast Rotor for 2015-2026 Mercedes E/GLC/CLS/EQC

Vehicle Fitment

• 2015-2022 Mercedes-Benz GLC (X253, 2.0L I4/2.1L I4 Diesel, RWD/4Matic AWD, applicable brake configuration)
• 2016-2023 Mercedes-Benz E-Class (W213, 3.0L V6/3.5L V6/3.0L I6, 4Matic AWD, applicable brake configuration)
• 2016-2023 Mercedes-Benz E-Class T-Model (S213, 2.0L I4 Diesel/3.0L V6/3.5L V6/3.0L I6, RWD/4Matic AWD)
• 2017-2023 Mercedes-Benz E-Class All-Terrain (S213, 3.0L I6, 4Matic AWD)
• 2017-2026 Mercedes-Benz E-Class Coupe (C238, 3.0L V6/3.0L I6, 4Matic AWD)
• 2017-2026 Mercedes-Benz E-Class Convertible (A238, 3.0L V6/3.0L I6, 4Matic AWD)
• 2017-2026 Mercedes-Benz CLS (C257, 3.0L I6, 4Matic/4Matic+ AWD)
• 2019-2023 Mercedes-Benz EQC (N293, electric, 4Matic AWD)

Fitment Notes

• Rear axle application; left and right rear positions use the same rotor.
• Requires the specific 360 mm x 26 mm rear brake configuration.
• Applicable powertrains include gasoline, diesel, mild-hybrid, plug-in hybrid, and electric configurations where the factory brake specification matches.
• GLC X253 applications include selected 200 EQ Boost, 220 d, 220 d 4Matic, 250 d 4Matic, 300 4Matic, 300 e 4Matic, 300 EQ Boost 4Matic, and F-CELL configurations.
• E-Class applications include selected E400, E450, AMG E43, AMG E53, and compatible E300 de configurations.
• CLS applications include CLS450 EQ Boost 4Matic and AMG CLS53 EQ Boost 4Matic+ configurations.
• EQC applications are limited to the compatible 360 mm rear brake configuration.
• 2024-2026 E-Class/CLS coverage is dependent on the applicable model and exact factory brake configuration; verify the OE number before ordering.

Features

• Brembo Prime Line Co-Cast rear brake rotor.
• 360 mm outside diameter provides the specified braking surface.
• 26 mm nominal thickness matches the compatible factory brake configuration.
• 23.4 mm minimum thickness defines the specified service limit.
• Two-piece bi-material construction combines a steel hat with a high-carbon cast-iron friction ring.
• Co-Cast construction can reduce rotor weight by up to 15% compared with conventional designs.
• PVT ventilation technology promotes efficient heat dissipation.
• High-carbon cast iron provides enhanced thermal stability and fade resistance.
• UV-coated surface helps protect exposed rotor surfaces against corrosion.
• 69 mm centering diameter provides the specified hub interface.
• Five-hole mounting pattern matches compatible Mercedes-Benz applications.
• ECE-R90 type-approved OE-equivalent design.

Specifications

• Brand: Brembo
• Part Number: 09.D532.13
• Product Line: Prime
• Product Type: Co-Cast Brake Disc Rotor
• Position: Rear
• Fitting Side: Left/Right
• Outside Diameter: 360 mm
• Nominal Thickness: 26 mm
• Minimum Thickness: 23.4 mm
• Overall Height: 49 mm
• Centering Diameter: 69 mm
• Mounting Holes: 5
• Brake Disc Type: Internally Ventilated
• Construction: Two-Piece Co-Cast
• Hat Material: Steel
• Friction Ring Material: High-Carbon Cast Iron
• Ventilation Technology: PVT
• Surface: Coated
• ECE-R90 Type Approved: Yes
• OE References: 0004231712, A0004231712
• EAN: 8020584233764

Included Components

• 1x Brembo 09.D532.13 Rear Brake Rotor
• 1x Fixing Screw Kit

Product Description

The Brembo 09.D532.13 Prime Co-Cast Rear Brake Rotor is an OE-equivalent replacement designed for selected Mercedes-Benz E-Class, GLC, CLS, and EQC applications using the 360 mm rear brake configuration. Measuring 360 mm in diameter and 26 mm in nominal thickness, the rotor is internally ventilated and engineered for the demanding braking requirements of compatible Mercedes-Benz passenger, performance, hybrid, and electric vehicles.

Brembo's Co-Cast construction combines a steel hat cast onto a high-carbon cast-iron braking surface, creating a two-piece bi-material rotor that can reduce weight by up to 15% compared with conventional construction. PVT ventilation improves heat management, while the coated surface provides corrosion protection. The rotor also uses a 69 mm center bore, five-hole mounting pattern, and 23.4 mm minimum thickness.

The 09.D532.13 is supplied individually with the required fixing hardware and is installed on either the left or right rear position. Fitment spans selected X253 GLC, W213/S213 E-Class, C238/A238 E-Class Coupe/Convertible, C257 CLS, and N293 EQC applications. Because these vehicles were offered with multiple brake systems and powertrains, confirm the factory 360 mm rear rotor specification and OE reference before installation.
